D24VA100UNVA-A 96 Watt LED 4150mA Constant Voltage Driver

Universal Lighting SKU: D24VA100UNVA-A
Universal Lighting D24VA100UNVA-A 96 Watt LED 4150mA Constant Voltage Driver

D24VA100UNVA-A 96 Watt LED 4150mA Constant Voltage Driver

Universal Lighting SKU: D24VA100UNVA-A
Regular price $66.76 Sale price $62.73 Save 6%
Limited quantity available
Please Call To Order
  • Free Economy Shipping on Orders Over $750
  • Secure Payments

Universal Lighting Technologies Everline® LED drivers are ideal for maximum energy savings and control applications. These LED power supplies are proven in the field and feature (depending on driver) high efficiency Constant Voltage, high range voltage or universal voltage, Class B transient surge protection and/or dimming functionally. If you need an LED driver replacement be sure to ask for Everline® to make sure your application will operate to its full potential.

This item is the Universal Everline LED power supply part number D24VA100UNVA-A. The input voltage is a universal 120-277 volt and has a 24V constant voltage output. This LED driver is 0-10V dimmable. The constant current output is 4150mA (4.15 Amps) with 96 watt maximum output power. Each color coded lead is 8 inches long. Universal's Everline LED power supplies are UL Dry and Damp Location Rated, FCC Part 15 Class A for non-consumer limits.

Universal Lighting Technologies warrants to the purchaser that each power supply will be free from defects in material or workmanship for a period of 5 years from the date of manufacture when properly installed per instructions and under normal operating conditions of use.

Manufacturer Universal Lighting
UPC 768386586470
Lighting Technology LED
Driver Constant Voltage
Output Current 4.15A (4150mA)
Input Current 0.93A @120V; 0.4A @277V
Input Wattage 112 Watt
Output Wattage 96 Watt
Input Voltage 120-277VAC
Output Voltage 24VDC
Frequency 50/60Hz
Power Factor >0.90
THD (Total Harmonic Distortion) Power <10%
Operating Temperature -40°C to 60°C
Dimensions 9.50" L x 1.70" W x 1.18" H
Certifications Class 2, RoHS Compliant, FCC
Environment Dry and Damp Location
Warranty 5 Year Limited

Green Electrical Supply will help you maximize your green® on all your electrical supply purchases, including projects, bids, quotes, and large orders.

Simply use our Contact Us form to request a quote. Or if you prefer, give us a call at 248-276-9640. Weekdays 8am-5pm EST

Tip: Copy the SKU from above and include it along with the quantity on the quote request.
Please note that the SKU is dynamic and changes on products that have multiple options, so choose the required option(s) first to see the precise SKU.
