3 Foot 11 Watt LED T8 Single/Double Ended Bypass Tube Light 30/35/40/50/65K

Green Creative SKU: 37228
Green Creative 3 Foot 11 Watt LED T8 Single/Double Ended Bypass Tube Light 30/35/40/50/65K Selectable

3 Foot 11 Watt LED T8 Single/Double Ended Bypass Tube Light 30/35/40/50/65K

Green Creative SKU: 37228
  • DLC Listed, Enclosed Fixture Rated
/
Color Temp
Please call to confirm availability.
**BALLAST MUST BE BYPASSED IN ORDER TO USE**
Shipping calculated at checkout.
  • Free Shipping on Orders Over $750
  • Most in-stock items ship the same day!

The Green Creative ballast bypass tube light is a reliable and energy efficient alternative to traditional T8 fluorescent lamps, operating directly on 120-277V line voltage. With up to 140 LPW, a 220° light emitting area, and a L70 rated lifetime of up to 60,000 hours, this tube light is a great choice to reduce glare and save energy.

The Green Creative 3 foot single or double ended tube light tube is color selectable, allowing you to chose from 5 different color temperatures with just a switch. This ballast bypass tube light generates between 1,425-1,545 lumens depending on the color temperature selected. These lamps consume 11 watts of power and are compatible with 120-277 line voltages. The physical dimensions of the Green Creative color selectable tube light are 35-3/4 inches MOL by 1-1/8 inches diameter. Each 11T8/3F/8CCTS/UEB (37228) T8 tube light carries a 5 year limited warranty.

Manufacturer Green Creative
MPN 11T8/3F/8CCTS/UEB
SKU 37228
UPC 790492372289
Lighting Technology LED
Wattage 11 Watts
Voltage 120-277V
Color Temperature (Kelvin) 3000K Warm White 3500K Bright White 4000K Cool White 5000K Daylight 6500K Daylight
Lumens 1,425 Lumens 1,545 Lumens 1,545 Lumens 1,545 Lumens 1,500 Lumens
Efficiency (Lumens Per Watt) 130 LPW 140 LPW 140 LPW 140 LPW 136 LPW
Ballast Operation Type B, Ballast Bypass
Wiring Method Single or Double Ended
Bulb Shape T8
Base G13 Medium Bi-Pin
Beam Angle 220 Degrees
Rated Life 60,000 Hours
CRI (Color Rendering Index) 82 CRI
Power Factor 0.9
THD (Total Harmonic Distortion) <20%
Fluorescent Equivalent 25 Watts
Operating Temperature -4°F to 95°F (-20°C to 35°C)
Dimensions 35-3/4" MOL x 1-1/8" Diameter
Certifications DLC Listed, Enclosed Fixture Rated, FCC
DLC Product ID S-VJMN1L
Environment Damp Locations
Warranty 5 Year Limited

Green Creative LED Selectable Bypass T8 Tube Light Specification Sheet

Green Creative LED Selectable Bypass T8 Tube Light Installation Instructions

Green Creative LED Selectable Bypass T8 Tube Light DLC Product Listing

   
