4 Foot 18/28/44 Watt Wattage and Color Selectable LED Curved Wrap Fixture 35/4/5K

Keystone Technologies SKU: KT-CWLED44PS-4-8CSA-VDIM
Keystone Technologies 4 Foot 18/28/44 Watt Wattage and Color Selectable LED Curved Wrap Fixture 35/4/5K Selectable

4 Foot 18/28/44 Watt Wattage and Color Selectable LED Curved Wrap Fixture 35/4/5K

Keystone Technologies SKU: KT-CWLED44PS-4-8CSA-VDIM
  • DLC Listed
Regular price $129.73
/
Color Temp
Please call to confirm availability.
Shipping calculated at checkout.
  • Free Shipping on Orders Over $750
  • Most in-stock items ship the same day!

Keystone’s XFit wrap fixtures are designed to deliver general purpose lighting for surface-mount ceiling applications and are the ideal choice for schools, offices, and retail locations. Surface mount wraparound fixtures deliver all-around illumination, and are often used in indoor applications that require typical functional light levels without a recessed ceiling grid in place. Available with Keystone’s Power Select and Color Select technologies, which allow users to choose from among a variety of power outputs and color temperatures by flicking a switch. Powered by a Keystone driver, these LED wrap light fixtures deliver up to 135 lm/W to provide 50% energy savings. With a useful life of at least 5 years, XFit wrap fixtures will also reduce maintenance and replacement costs compared to fluorescent fixtures.

This item is the DLC Listed, Keystone Technologies KT-CWLED44PS-4-8CSA-VDIM. This Keystone Technologies LED Wrap fixture consumes a selectable amount of 18/28/44 watts of 120-277 volt energy. They generate between 2,628-6,116 lumens (136-148 lumens per watt), have a rated lumen maintenance of 100,000 hours based on L70 lumen depreciation, a selectable color temperature of 3500K bright white, 4000K cool white or 5000K daylight and a CRI of 80. These LED wrap light have a 0-10V dimmable configuration. All Keystone LED wrap fixtures carry a 5 Year Limited Warranty.

Manufacturer Keystone Technologies
MPN KT-CWLED44PS-4-8CSA-VDIM
SKU KT-CWLED44PS-4-8CSA-VDIM
UPC 843654137292
Lighting Technology LED
Voltage 120-277V
Dimmable Yes, 0-10V Dimming
Rated Life 100,000 Hours
CRI (Color Rendering Index) 80 CRI
Power Factor >0.95
THD (Total Harmonic Distortion) <20%
Operating Temperature -20°C to 45°C
Dimensions 46" L x 9.7" W x 3.4"H
DLC Product ID P3VQ2JYW
Warranty 5 Year Warranty



Wattage 18 Watts
Color Temperature (Kelvin) 3500K Bright White 4000K Cool White 5000K Daylight
Lumens 2,628 Lumens 2,646 Lumens 2,664 Lumens
Efficiency (Lumens Per Watt) 146 LPW 147 LPW 148 LPW



Wattage 28 Watts
Color Temperature (Kelvin) 3500K Bright White 4000K Cool White 5000K Daylight
Lumens 4,004 Lumens 4,032 Lumens 4,060 Lumens
Efficiency (Lumens Per Watt) 143 LPW 144 LPW 145 LPW



Wattage 44 Watts
Color Temperature (Kelvin) 3500K Bright White 4000K Cool White 5000K Daylight
Lumens 5,984 Lumens 6,072 Lumens 6,116 Lumens
Efficiency (Lumens Per Watt) 136 LPW 138 LPW 139 LPW
