CM 6 R Remote High Bay Sensor

Acuity Controls SKU: CM 6 R
Acuity Controls CM 6 R Remote High Bay Sensor White

CM 6 R Remote High Bay Sensor

Acuity Controls SKU: CM 6 R
Regular price $119.00 Sale price $103.15 Save $15.85
Finish Color
Limited quantity available
Shipping calculated at checkout.
  • Free Shipping on Orders Over $750
  • Secure payments

Acuity Brands is here to offer you their extensive line of lighting controls. Sensor Switch offers one of the industry's broadest selections of occupancy sensors, photocell devices, panels, switches, fixture-level and wireless controls for indoor and outdoor applications, single rooms or even campuses and municipalities. Using digital passive infrared (PIR) detection and Microphonics technology, these sensors accurately respond to occupant behavior.

The CM family of ceiling mount occupancy sensors provide a range of sensor solutions for applications with finished ceilings (ex. ceiling tiles, sheetrock and plaster). The CM family sensors utilize 100% digital Passive Infrared (PIR) detection and are available with several lens options, providing flexibility for multiple mounting heights and coverage patterns. Lens options include large motion extended range, small motion standard range, and bi-directional for hallways. Multiple of these low voltage sensors can work together to supply the ideal solution for oddly shaped rooms or large open office areas. For rooms with obstructions or with limited movement, dual technology (PDT) occupancy detection can also be added as an option. Contact us if you would like a product you do not see here.

This is item number CM 6 R, a high mount 360° coverage pattern ceiling occupancy sensor with a low voltage relay. This sensor is push-button programmable with adjustable time delays and multiple operating modes. This model is the best choice for large motion detection (ex. walking) and extra large motion (ex. forklifts) as it has a 360° conical shaped pattern. For mounting heights between 15 and 45 feet, this occupancy sensor will fit your application perfectly. The 15 to 20 feet of radial coverage overlaps area lit by a typical high bay fixture. Detection range does improve when walking across beams compared to into beams. This sensor has been tested to the NEMA WD 7-2011 standards. Time delays can be as little as 30 seconds and as large as 20 minutes. This motion detector sensor does come with a green LED indicator and a 100 hour lamp burn-in timer mode. This sensor does require a power pack (PP20 recommended) if you are running 120V. Up to 14 sensors can be used on the same power pack.

For installation purposes, mount the sensor directly to a ceiling tile or a metallic grid (two self-tapping screws are provided). The sensor also features mounting holes that align with 3.5" octagon or single gang handy boxes (screws not provided). For optimal detection, position sensor such that segments are crossed upon entrance and unable to view outside the space. Because this sensor has the relay option included, the relay is energized during the unoccupied state. See specification sheet for the wiring diagram and wiring instructions.
