Name: 40/50/60 Watt Selectable 2X4 Backlit Panel 3500/4000/5000K Gen 3
Brand: Keystone Technologies
SKU: KT-BPLED60PS-24-8CSA-VDIM /G3
Price: 92.23 USD
Availability: InStock

Keystone Technologies 40/50/60 Watt Selectable 2X4 Backlit Panel 3500/4000/5000K Gen 3 Selectable

Keystone Technologies 40/50/60 Watt Selectable 2X4 Backlit Panel 3500/4000/5000K Gen 3

Damp Location Rated, DLC Premium Listed

Price

Color Temp

Selectable

Quantity

Free Shipping on Orders Over $750 (contiguous US only)

Most in-stock items ship the same day!

Helping you maximize your green® since 2007!

[{"id":47065218482420,"title":"Selectable","option1":"Selectable","option2":null,"option3":null,"sku":"KT-BPLED60PS-24-8CSA-VDIM \/G3","requires_shipping":true,"taxable":true,"featured_image":{"id":49093419434228,"product_id":9172429996276,"position":1,"created_at":"2025-10-21T13:50:30-04:00","updated_at":"2025-10-21T13:50:31-04:00","alt":"Keystone Technologies 40\/50\/60 Watt Selectable 2X4 Backlit Panel 3500\/4000\/5000K Gen 3 Selectable","width":600,"height":120,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/files\/KT-BPLED60PS-24-8CSA-VDIM-G3-3.webp?v=1761069031","variant_ids":[47065218482420]},"available":true,"name":"40\/50\/60 Watt Selectable 2X4 Backlit Panel 3500\/4000\/5000K Gen 3 - Selectable","public_title":"Selectable","options":["Selectable"],"price":9223,"weight":5216,"compare_at_price":null,"inventory_management":"shopify","barcode":"843654171685","featured_media":{"alt":"Keystone Technologies 40\/50\/60 Watt Selectable 2X4 Backlit Panel 3500\/4000\/5000K Gen 3 Selectable","id":40310155378932,"position":1,"preview_image":{"aspect_ratio":5.0,"height":120,"width":600,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/files\/KT-BPLED60PS-24-8CSA-VDIM-G3-3.webp?v=1761069031"}},"requires_selling_plan":false,"selling_plan_allocations":[]}]

Details
Specifications
Documents
Request A Quote

Details

Keystone's Backlit LED panel lights offer a dependable, effortless installation that delivers superior light diffusion to commercial spaces such as offices and schools. Its sleek, lightweight construction contains 4 knockouts for simple integration into existing or new construction projects. Coupled with a Keystone 0-10V dimming LED driver, the back-lit panel lights offer seamless, uniform dimming functionality.

Hot spots and yellowing have been long-standing issues with LED back-lit panel light fixtures. Keystone eliminated those concerns by covering each LED chip with a frosted lens for diffusion, guaranteeing a uniform light quality without any hot spots. This feature is further bolstered by optical lenses that protect each LED chip from yellowing. Keystone's new back-lit panel light fixtures incorporate Power Select and Color Select features, allowing users to switch between different lumen outputs and color temperatures, thereby reducing SKUs.

This Keystone Technologies KT-BPLED60PS-24-8CSA-VDIM/G3 color and wattage select flat panel operates at 40/50/60 watts of 120-277 volt energy, producing 5,760-8,200 lumens (132-148 lumens per watt) and rated at 100,000-hour life expectancy (L70 lumen depreciation). Selectable color temperatures of 3500K Bright White, 4000K Cool White, or 5000K Daylight offer a CRI of 80. This product is backed by a 10-Year Limited Warranty.

Specifications

Manufacturer	Keystone Technologies
MPN	KT-BPLED60PS-24-8CSA-VDIM /G3
SKU	KT-BPLED60PS-24-8CSA-VDIM /G3
UPC	843654171685
DLC Product ID	S-YK83YP
Lighting Technology	LED
Voltage	120-277V
Dimmable	Yes, 0-10V
Rated Life	100,000 Hours
CRI (Color Rendering Index)	80 CRI
Power Factor	>0.9
Operating Temperature	-20ºC/-4ºF to 40ºC/104ºF
Dimensions	47.71"L x 23.74"W x 1.37"H
Environment	Damp Location Rated
Certifications	DLC Premium Listed, NSF
Warranty	10 Year Warranty

Wattage	40 Watts
Color Temperature (Kelvin)	3500K Bright White	4000K Cool White	5000K Daylight
Lumens	5,500 Lumens	5,920 Lumens	5,760 Lumens
Efficiency (Lumens Per Watt)	144 LPW	148 LPW	138 LPW

Wattage	50 Watts
Color Temperature (Kelvin)	3500K Bright White	4000K Cool White	5000K Daylight
Lumens	6,700 Lumens	7,000 Lumens	6,850 Lumens
Efficiency (Lumens Per Watt)	135 LPW	140 LPW	137 LPW

Wattage	50 Watts
Color Temperature (Kelvin)	3500K Bright White	4000K Cool White	5000K Daylight
Lumens	7,900 Lumens	8,200 Lumens	8,000 Lumens
Efficiency (Lumens Per Watt)	132 LPW	137 LPW	134 LPW

Documents

Keystone 2X4 Backlit Panel Specification Sheet

Keystone 2X4 Backlit Panel Installation Instructions

Keystone 2X4 Backlit Panel DLC Product Listing
