80/100/120/150 Watt Selectable LED Surface Mount Canopy Light 5000K

Westgate SKU: GSX-SRFC-80-150W-50K
  • DLC Premium Listed, IP65, Wet Location Rated
/
Color Temp
Finish Color
  • Free Shipping on Orders Over $750 (contiguous US only)
  • Most in-stock items ship the same day!
  • Helping you maximize your green® since 2007!
Details

Westgate's LED recessed under canopy is ideal for airports, auto dealerships, corporate offices, education, government, healthcare, industrial warehouses, municipal parking, gas stations, convenient stores, recreation and public venues, restaurants, hospitality, retail and grocery stores. This LED light fixture offers a durable and high-quality solution in a white aluminum alloy housing with a polycarbonate lens redesigned for LED.

The Westgate 80/100/120/150 watt selectable surface mount LED canopy light is available in daylight 5000K. It produces 11200-21000 lumens for an amazing 140 lumens per watt. Operating on a universal 120-277 volt line, it has 0-10v dimming, a 100 x 100 degree beam, and is suitable for wet locations. DLC Premium listed and rated for 70,000 hours, this LED light fixture comes with a 7 year warranty.

Specifications
Manufacturer Westgate
MPN GSX-SRFC-80-150W-50K
SKU GSX-SRFC-80-150W-50K
UPC 845060072488
Lighting Technology LED
Wattage 80/100/120/150 Watts
Voltage 120-277V
Frequency 50/60 Hz
Color Temperature (Kelvin) 5000K Daylight
Lumens 11200-21000 Lumens
Efficiency (Lumens Per Watt) 140 lm/W
Dimmable Yes, 0-10V
Beam Angle 100° x 100°
Rated Life 70,000 Hours
CRI (Color Rendering Index) >70 CRI
Power Factor 0.95
Finish Color White
Housing ADC12 Aluminum Alloy
Lens Polycarbonate
Mounting Recessed
Operating Temperature -40°F to 104°F
Dimensions 20-1/2" W x 20-1/2" H x 7-2/5" D
Certifications DLC Premium Listed, UL Listed, IP 65
DLC Product ID PLV1AP3LJV3K
Environment Wet Location
BUG Rating B4-U2-G2
Warranty 7 Year
Documents

Westgate Watt Selectable LED Surface Mount Canopy Light Specification Sheet

Westgate Watt Selectable LED Surface Mount Canopy Light Installation Instructions

Westgate Watt Selectable LED Surface Mount Canopy Light DLC Product Listing
