IOS-DOV-D-WH Commercial Grade In-Wall 0-10V Dimming PIR Occupancy/Vacancy Sensor

Intermatic SKU: IOS-DOV-D-WH
Intermatic IOS-DOV-D-WH Commercial Grade In-Wall 0-10V Dimming PIR Occupancy/Vacancy Sensor
Intermatic IOS-DOV-D-WH Commercial Grade In-Wall 0-10V Dimming PIR Occupancy/Vacancy Sensor
Intermatic IOS-DOV-D-WH Commercial Grade In-Wall 0-10V Dimming PIR Occupancy/Vacancy Sensor
Intermatic IOS-DOV-D-WH Commercial Grade In-Wall 0-10V Dimming PIR Occupancy/Vacancy Sensor
Intermatic IOS-DOV-D-WH Commercial Grade In-Wall 0-10V Dimming PIR Occupancy/Vacancy Sensor
Intermatic IOS-DOV-D-WH Commercial Grade In-Wall 0-10V Dimming PIR Occupancy/Vacancy Sensor

IOS-DOV-D-WH Commercial Grade In-Wall 0-10V Dimming PIR Occupancy/Vacancy Sensor

Intermatic SKU: IOS-DOV-D-WH
/
Please call to confirm availability.
Shipping calculated at checkout.
  • Free Shipping on Orders Over $750
  • Most in-stock items ship the same day!

Intermatic’s IOS-DOV-D-WH PIR technology 0-10 V dimming occupancy sensor can turn lights ON and OFF based on occupancy and allow the user to increase or decrease the lighting level. It provides improved lighting control options and the ability to adjust lighting levels with 0-10V dimming for maximum savings on energy costs.

This IOS-DOV-D-WH Commercial Grade In-Wall 0-10V Dimming PIR Occupancy/Vacancy Sensor is designed for LED, Tungsten, and Standard Ballast applications. Mounted in your wall, this sensor features Passive Infrared (PIR) sensing to detect occupancy or vacancy. It comes complete with a white wall plate and requires a neutral connection.

Decorative Face Plate Included

Manufacturer Intermatic
MPN IOS-DOV-D-WH
SKU IOS-DOV-D-WH
UPC 078275154001
Lighting Technology LED; Tungsten; Standard Ballast
Input Voltage Range 120/277 VAC
Frequency 50/60Hz
Sensor Technology PIR (Passive Infrared)
Dimmable 0-10V Dimming
PIR Coverage Area 1120 Square Feet
PIR Coverage Pattern 35 Degrees
Neutral Connection Required Yes
Mounting In-Wall
Occupancy Sensor Power Type Line Voltage
Number of Circuits 1
Tungsten Range 1000 Watts
Resistive Load Ratings Ranges 10 A
Motor Load Ratings Ranges 1/6 HP
Electronic Ballast Load Ratings Ranges 600 VA, 120 VAC; 1385 Watts, 277 VAC
Adjustable Time Delay Minimum 30 Seconds
Adjustable Time Delay Maximum 30 Minutes
Adjustable Light Level Maximum Daylight
Operating Temperature 32°F (0°C) to 131°F (55°C)
Dimensions 4.625" H x 3" W x 2.19" Depth
Warranty 5 Year Limited



Specification Sheet

Installation Instructions

 

Green Electrical Supply will help you maximize your green® on all your electrical supply purchases, including projects, bids, quotes, and large orders.

Simply use our Contact Us form to request a quote. Or if you prefer, give us a call at 248-276-9640. Weekdays 8am-5pm EST

Tip: Copy the SKU from above and include it along with the quantity on the quote request.
Please note that the SKU is dynamic and changes on products that have multiple options, so choose the required option(s) first to see the precise SKU.
