Name: 10/20/30 Watt 120-277V Square New Concept LED Garage Ceiling Light 3000K/4000K/5000K
Brand: Westgate
SKU: CXES-10-30W-MCTP
Price: 55.23 USD
Availability: InStock

10/20/30 Watt 120-277V Square New Concept LED Garage Ceiling Light 3000K/4000K/5000K

DLC Premium Listed

Price

Color Temp

Selectable

Finish Color

Bronze

White

Quantity

Free Shipping on Orders Over $750 (contiguous US only)

Most in-stock items ship the same day!

Helping you maximize your green® since 2007!

[{"id":46983667810548,"title":"Selectable \/ Bronze","option1":"Selectable","option2":"Bronze","option3":null,"sku":"CXES-10-30W-MCTP","requires_shipping":true,"taxable":true,"featured_image":{"id":48840890089716,"product_id":9154860450036,"position":1,"created_at":"2025-10-01T12:46:18-04:00","updated_at":"2025-10-01T12:46:20-04:00","alt":null,"width":800,"height":800,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/files\/Westgate_CXESMAIN10-30w.webp?v=1759337180","variant_ids":[46983667810548]},"available":true,"name":"10\/20\/30 Watt 120-277V Square New Concept LED Garage Ceiling Light 3000K\/4000K\/5000K - Selectable \/ Bronze","public_title":"Selectable \/ Bronze","options":["Selectable","Bronze"],"price":5523,"weight":1134,"compare_at_price":null,"inventory_management":"shopify","barcode":"845060091601","featured_media":{"alt":null,"id":40077531119860,"position":1,"preview_image":{"aspect_ratio":1.0,"height":800,"width":800,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/files\/Westgate_CXESMAIN10-30w.webp?v=1759337180"}},"requires_selling_plan":false,"selling_plan_allocations":[]},{"id":46983667843316,"title":"Selectable \/ White","option1":"Selectable","option2":"White","option3":null,"sku":"CXES-10-30W-MCTP-WH","requires_shipping":true,"taxable":true,"featured_image":{"id":48841600598260,"product_id":9154860450036,"position":4,"created_at":"2025-10-01T14:33:37-04:00","updated_at":"2025-10-01T14:39:13-04:00","alt":null,"width":800,"height":800,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/files\/Westgate_CXES-4_2_white_main_resized.webp?v=1759343953","variant_ids":[46983667843316]},"available":true,"name":"10\/20\/30 Watt 120-277V Square New Concept LED Garage Ceiling Light 3000K\/4000K\/5000K - Selectable \/ White","public_title":"Selectable \/ White","options":["Selectable","White"],"price":5831,"weight":1134,"compare_at_price":null,"inventory_management":"shopify","barcode":"845060091663","featured_media":{"alt":null,"id":40078160429300,"position":4,"preview_image":{"aspect_ratio":1.0,"height":800,"width":800,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/files\/Westgate_CXES-4_2_white_main_resized.webp?v=1759343953"}},"requires_selling_plan":false,"selling_plan_allocations":[]}]

{"id":46983667810548,"title":"Selectable \/ Bronze","option1":"Selectable","option2":"Bronze","option3":null,"sku":"CXES-10-30W-MCTP","requires_shipping":true,"taxable":true,"featured_image":{"id":48840890089716,"product_id":9154860450036,"position":1,"created_at":"2025-10-01T12:46:18-04:00","updated_at":"2025-10-01T12:46:20-04:00","alt":null,"width":800,"height":800,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/files\/Westgate_CXESMAIN10-30w.webp?v=1759337180","variant_ids":[46983667810548]},"available":true,"name":"10\/20\/30 Watt 120-277V Square New Concept LED Garage Ceiling Light 3000K\/4000K\/5000K - Selectable \/ Bronze","public_title":"Selectable \/ Bronze","options":["Selectable","Bronze"],"price":5523,"weight":1134,"compare_at_price":null,"inventory_management":"shopify","barcode":"845060091601","featured_media":{"alt":null,"id":40077531119860,"position":1,"preview_image":{"aspect_ratio":1.0,"height":800,"width":800,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/files\/Westgate_CXESMAIN10-30w.webp?v=1759337180"}},"requires_selling_plan":false,"selling_plan_allocations":[]}

Details
Specifications
Documents
Video
Request A Quote

Details

Westgate's Builder Series Square New Concept LED Garage Ceiling Light is ideal for indoor parking lots, commercial buildings, schools, warehouses, retail centers, and apartment complexes. Designed for 9 to 16-foot mounting, this LED light fixture offers a durable and high-quality solution in either a bronze or white stamped galvanized steel housing with a prismatic polycarbonate lens redesigned for LED.

The Westgate 10/20/30 watt selectable LED square ceiling garage light is CCT selectable with warm white 3000K, cool white 4000K and daylight 5000K options. It produces 1300-3900 lumens for an amazing 130 lumens per watt. Operating on a universal 120-277 volt line, it has 0-10v dimming, a 150 degree beam, and is suitable for damp locations. Rated 70,000 hours, this LED light fixture is DLC Premium listed and comes with a 7 year warranty.

Specifications

Manufacturer	Westgate
Finish Color	Bronze	White
MPN	CXES-10-30W-MCTP	CXES-10-30W-MCTP-WH
SKU	CXES-10-30W-MCTP	CXES-10-30W-MCTP-WH
UPC	845060091601	845060091663
Lighting Technology	LED
Wattage	10/20/30 Watts
Voltage	120-277V
Frequency	50/60 Hz
Color Temperature (Kelvin)	3000K/4000K/5000K
Lumens	1300/2600/3900 Lumens
Efficiency (Lumens Per Watt)	130 lm/W
Dimmable	Yes, 0-10V
Beam Angle	150°
Rated Life	70,000 Hours
CRI (Color Rendering Index)	>70 CRI
Power Factor	0.9
Housing	Stamped Galvanized Steel
Lens	Prismatic Polycarbonate
Operating Temperature	-40°F to 104°F
Dimensions	9-1/8" L x 9-1/8" W x 3-1/8" H
Certifications	DLC Premium Listed, UL Listed
DLC Product ID	S-M6L9JA
Environment	Damp Location
BUG Rating	B2-U3-G2
Warranty	7 Year

Documents

Westgate 10/20/30 Watt Square New Concept LED Garage Ceiling Light Specification Sheet - Bronze

Westgate 10/20/30 Watt Square New Concept LED Garage Ceiling Light Specification Sheet - White

Westgate 10/20/30 Watt Square New Concept LED Garage Ceiling Light Installation Instructions

Westgate 10/20/30 Watt Square New Concept LED Garage Ceiling Light DLC Product Listing
