11 Inch 22/30W Rectangular Power and Color Selectable LED Light Engine 3000/3500/4000/5000K

Keystone Technologies SKU: KT-RKIT30PS-11RP-8CSC-VDIM
Keystone Technologies 11 Inch 22/30W Rectangular Power and Color Selectable LED Light Engine 3000/3500/4000/5000K Selectable

11 Inch 22/30W Rectangular Power and Color Selectable LED Light Engine 3000/3500/4000/5000K

Keystone Technologies SKU: KT-RKIT30PS-11RP-8CSC-VDIM
  • Energy Star
Regular price $74.38
/
Color Temp
  • Free Shipping on Orders Over $750
  • Most in-stock items ship the same day!
  • Helping you maximize your green® since 2007!

The FutureFit line of LED light engines are now more versatile and efficient with Power Select and Color Select. These innovative features allow the lumen output and color temperature to be selected with a simple switch. The linear LED modules with Aluma Groove are pre-mounted into an aluminum extension via a patented manufacturing method. These high efficiency LED light engines are equipped with Power Select switches for lumen output versatility.

The Keystone 11 Inch FutureFit engine comes in a selectable wattage of 22 and 29.5W. This LED rectangular light engine produces a selectable lumen output between 3,100-4,200 with a selectable color temperature of 3000K warm white, 3500K bright white, 4000K cool white and 5000K daylight. The default setting on the light engine will be set at 29.5 Watts and 5000K Daylight. This wattage and color selectable engine operated on the universal voltage of 120-277V, making it a high-performance, cost-effective replacement for incandescent, CFL, and rectangular light sources in residential and commercial ceiling fixtures, including flush mount ceiling lights. This led module is 11.02" in overall length with a thickness of only 0.23".

FutureFit LED retrofit kits are pre-packaged with your desired LED module, a Keystone driver, and mounting accessories for easy installation either in the field or at the point of manufacture. With each LED light engine already safety tested and performance verified, upgrading to LED doesn’t get any easier than FutureFit LED retrofit kits. These products are perfect for retrofitting your fluorescent wall scones and ceiling luminaries. The LED retrofits for existing fixtures feature dimming 0-10V, making this product perfect for any application including but not limited to: residential home lighting, hotel applications, restaurant lighting, retail applications, parking garage lighters and more. The FutureFit LED kits carry a 10 year warranty.

Manufacturer Keystone Technologies
MPN KT-RKIT30PS-11RP-8CSC-VDIM
SKU KT-RKIT30PS-11RP-8CSC-VDIM
UPC 843654128139
Lighting Technology LED
Voltage 120-277V
Beam Angle 120 Degrees
Rated Life 50,000 Hours
CRI (Color Rendering Index) >80 CRI
THD (Total Harmonic Distortion) <20%
Operating Temperature –20ºC/–4ºF to 45ºC/113ºF
Dimensions 11.02" L x 5.51" W x 0.23" H
Certifications RoHS, cULus, NLB, Energy Star
Environment Damp Location
Warranty 10 Year Limited



Wattage 22 Watts
Color Temperature (Kelvin) 3000K Warm White 3500K Bright White 4000K Cool White 5000K Daylight
Lumens 3,100 Lumens 3,125 Lumens 3,150 Lumens 3,200 Lumens
Efficiency (Lumens Per Watt) 141 lm/W 142 lm/W 143 lm/W 145 lm/W



Wattage 29.5 Watts
Color Temperature (Kelvin) 3000K Warm White 3500K Bright White 4000K Cool White 5000K Daylight
Lumens 4,100 Lumens 4,125 Lumens 4,150 Lumens 4,200 Lumens
Efficiency (Lumens Per Watt) 139 lm/W 140 lm/W 141 lm/W 142 lm/W
