14 Watt Color selectable LED PL Lamp GX32d-2 Base 2700K/4000K/5000K

Satco SKU: S11545
  • Title 24 Compliant, Title 20 Compliant
/
**BALLAST MUST BE BYPASSED IN ORDER TO USE**
  • Free Shipping on Orders Over $750 (contiguous US only)
  • Most in-stock items ship the same day!
  • Helping you maximize your green® since 2007!
Details

Upgrade outdated CFLs with SATCO|NUVO’s Type B ballast bypass LED replacement lamps—designed for direct-wire installation, eliminating the need for a ballast and reducing maintenance costs. These PL-shaped lamps provide uniform illumination with a wide 320-degree beam angle, while their durable aluminum and plastic construction with a frosted lens ensures smooth, omni-directional lightin

The Satco S11545 14W model replaces a traditional 22W CFL, and is CCT selectable, allowing users to choose between warm 2700K, neutral 4000K, or crisp 5000K light to suit various applications. Engineered with a damp location rating and GX32d-2 base, these energy-efficient lamps offer a simple, long-lasting upgrade for commercial and residential applications.

Specifications
Manufacturer Satco
MPN S11545
SKU S11545
UPC 045923115455
Lighting Technology LED
Wattage 14 Watt
Voltage 120-277V
Color Temperature (Kelvin) 2700K/4000K/5000K
Lumens 1400 Lumens
Efficiency (Lumens Per Watt) 100 LPW
Bulb Shape PL
Base GX32d-2
Dimmable Non Dimming
Ballast Operation Type B Ballast Bypass
Burn Position Universal
Beam Angle 320 Degrees
Rated Life 15,000 Hours
CRI (Color Rendering Index) 80+
Power Factor >0.9
THD (Total Harmonic Distortion) <20%
Fluorescent Equivalent 22 Watt
Operating Temperature -20°C (-4°F) to 40°C (104°F)
Certifications cETLus, Title 20/24 Compliant
Environment Damp Location Rated
Warranty 3 Year Warranty
