17 Watt Type B Bypass CFL Replacement PLT Light Bulb 2-Pin GX24d Base 3000K/3500K/4000K/5000K

Satco SKU: S29888
17 Watt Type B Bypass CFL Replacement PLT Light Bulb 2-Pin GX24d Base 3000K/3500K/4000K/5000K
17 Watt Type B Bypass CFL Replacement PLT Light Bulb 2-Pin GX24d Base 3000K/3500K/4000K/5000K
17 Watt Type B Bypass CFL Replacement PLT Light Bulb 2-Pin GX24d Base 3000K/3500K/4000K/5000K
17 Watt Type B Bypass CFL Replacement PLT Light Bulb 2-Pin GX24d Base 3000K/3500K/4000K/5000K
17 Watt Type B Bypass CFL Replacement PLT Light Bulb 2-Pin GX24d Base 3000K/3500K/4000K/5000K
17 Watt Type B Bypass CFL Replacement PLT Light Bulb 2-Pin GX24d Base 3000K/3500K/4000K/5000K

17 Watt Type B Bypass CFL Replacement PLT Light Bulb 2-Pin GX24d Base 3000K/3500K/4000K/5000K

Satco SKU: S29888
  • Damp Location Rated, Enclosed Fixture Rated, NSF Listed
/
Color Temp
  • Free Shipping on Orders Over $750 (contiguous US only)
  • Most in-stock items ship the same day!
  • Helping you maximize your green® since 2007!
Details

Upgrade existing CFL installations with versatile omnidirectional LED PLT lamps designed for performance and flexibility. Available in 7W, 9W, 15W, 17W, and 23W options with GX24d base, these energy-efficient replacements offer seamless compatibility with a wide range of fixtures. Type B operation allows use in ballast bypass applications, simplifying upgrades and reducing installation time. Featuring four selectable CCT options and a broad 120V–277V voltage range, these lamps deliver adaptable, reliable lighting for diverse commercial applications.

The Satco S29888 (17WPLTL/8CCT4/GX24D/OB/U) is 17-Watt GX24d (2-Pin) (Compatible with GX24q, G24d and G24q Sockets) Type B Ballast Bypass PLT Lamp that operates on 120-277V and has four color selectable options 3000K, 3500K, 4000K or 5000K. This lamp is enclosed fixture rated and carries a 5-year warranty.

Specifications
Manufacturer Satco
MPN 15WPLTL/8CCT4/GX24D/OB/U
SKU S29888
UPC 045923413421
Lighting Technology LED
Wattage 17 Watt
Lumens 2500 Lumens
Efficiency (Lumens Per Watt) 147 LPW
Color Temperature 3000/3500/4000K/5000K
Voltage 120-277V
Ballast Operation Type B Bypass
Base GX24d Base
Beam Angle 360 Degrees
Rated Life 50,000 Hours
CRI (Color Rendering Index) 80 CRI
Burn Position Universal
Operating Temperature -20C (-4F) to +45C (+113F)
Dimensions 6.70" MOL x 2.00" MOD
Certifications NSF, Enclosed Fixture Rated
Environment Damp Location Rated
Warranty 5 Year Warranty
Documents

Satco LED PLT Type B Bypass Lamp Specification Sheet

Satco LED PLT Type B Bypass Lamp Installation Instructions



Request A Quote

Green Electrical Supply is here to help you maximize your green® on all your electrical supply purchases.

Looking for a quote or need help finding an item, simply use our Contact Us form to request a quote, get assistance, or provide feedback. If you're more of a talker, feel free to give us a call at 248-276-9640 during our weekday hours from 8 am to 5 pm EST.

Here's a little tip to make your quote request even smoother: don't forget to copy the SKU from above and include it along with the quantity in your request. It's a small detail that ensures we get you the most accurate and efficient service. And, just a heads up, the SKU is dynamic, especially for products with multiple options. So, be sure to choose your required options first to view the precise SKU.
