Name: 18 Watt Color selectable LED PL Lamp GX32d-3 Base 2700K/4000K/5000K
Brand: Satco
SKU: S11546
Price: 17.47 USD
Availability: InStock

Satco 18 Watt Color selectable LED PL Lamp GX32d-3 Base 2700K/4000K/5000K

Title 24 Compliant, Title 20 Compliant

Price

Quantity

**BALLAST MUST BE BYPASSED IN ORDER TO USE**

Free Shipping on Orders Over $750 (contiguous US only)

Most in-stock items ship the same day!

Helping you maximize your green® since 2007!

Details
Specifications
Documents
Request A Quote

Details

Upgrade outdated CFLs with SATCO|NUVO’s Type B ballast bypass LED replacement lamps—designed for direct-wire installation, eliminating the need for a ballast and reducing maintenance costs. These PL-shaped lamps provide uniform illumination with a wide 320-degree beam angle, while their durable aluminum and plastic construction with a frosted lens ensures smooth, omni-directional lightin

The Satco S11546 18W model replaces a traditional 28W CFL, and is CCT selectable, allowing users to choose between warm 2700K, neutral 4000K, or crisp 5000K light to suit various applications. Engineered with a damp location rating and GX32d-3 base, these energy-efficient lamps offer a simple, long-lasting upgrade for commercial and residential applications.

Specifications

Manufacturer	Satco
MPN	S11546
SKU	S11546
UPC	045923115462
Lighting Technology	LED
Wattage	18 Watt
Voltage	120-277V
Color Temperature (Kelvin)	2700K/4000K/5000K
Lumens	1800 Lumens
Efficiency (Lumens Per Watt)	100 LPW
Bulb Shape	PL
Base	GX32d-3
Dimmable	Non Dimming
Ballast Operation	Type B Ballast Bypass
Burn Position	Universal
Beam Angle	320 Degrees
Rated Life	15,000 Hours
CRI (Color Rendering Index)	80+
Power Factor	>0.9
THD (Total Harmonic Distortion)	<20%
Fluorescent Equivalent	28 Watt
Operating Temperature	-20°C (-4°F) to 40°C (104°F)
Certifications	cETLus, Title 20/24 Compliant
Environment	Damp Location Rated
Warranty	3 Year Warranty
