Name: 180/240/300 Watt 120-277V Dynamic Beam Adjustable LED Extra Large Area Light 3000K/4000K/5000K
Brand: Westgate
SKU: LAX-XL-180-300W-MCTPD-PSR-BK
Price: 718.31 USD
Availability: InStock

Westgate 180/240/300 Watt 120-277V Dynamic Beam Adjustable LED Extra Large Area Light 3000K/4000K/5000K Selectable Black

Westgate 180/240/300 Watt 120-277V Dynamic Beam Adjustable LED Extra Large Area Light 3000K/4000K/5000K

Westgate 180/240/300 Watt 120-277V Dynamic Beam Adjustable LED Extra Large Area Light 3000K/4000K/5000K Selectable Bronze

DLC Premium Listed, IP65, Wet Location Rated

Price

Color Temp

Selectable

Finish Color

Black

Bronze

Quantity

Free Shipping on Orders Over $750 (contiguous US only)

Most in-stock items ship the same day!

Helping you maximize your green® since 2007!

[{"id":48645514887412,"title":"Selectable \/ Black","option1":"Selectable","option2":"Black","option3":null,"sku":"LAX-XL-180-300W-MCTPD-PSR-BK","requires_shipping":true,"taxable":true,"featured_image":{"id":52853606187252,"product_id":9509062738164,"position":1,"created_at":"2026-06-15T14:50:30-04:00","updated_at":"2026-06-15T14:50:31-04:00","alt":"Westgate 180\/240\/300 Watt 120-277V Dynamic Beam Adjustable LED Extra Large Area Light 3000K\/4000K\/5000K Selectable Black","width":2000,"height":2000,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/files\/LAX-XL-180-300W-MCTPD-PSR-BK_Main.webp?v=1781549431","variant_ids":[48645514887412]},"available":true,"name":"180\/240\/300 Watt 120-277V Dynamic Beam Adjustable LED Extra Large Area Light 3000K\/4000K\/5000K - Selectable \/ Black","public_title":"Selectable \/ Black","options":["Selectable","Black"],"price":71831,"weight":7874,"compare_at_price":null,"inventory_management":"shopify","barcode":"840378341257","featured_media":{"alt":"Westgate 180\/240\/300 Watt 120-277V Dynamic Beam Adjustable LED Extra Large Area Light 3000K\/4000K\/5000K Selectable Black","id":43879083278580,"position":1,"preview_image":{"aspect_ratio":1.0,"height":2000,"width":2000,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/files\/LAX-XL-180-300W-MCTPD-PSR-BK_Main.webp?v=1781549431"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":48645514920180,"title":"Selectable \/ Bronze","option1":"Selectable","option2":"Bronze","option3":null,"sku":"LAX-XL-180-300W-MCTPD-PSR","requires_shipping":true,"taxable":true,"featured_image":{"id":52853614051572,"product_id":9509062738164,"position":4,"created_at":"2026-06-15T14:50:50-04:00","updated_at":"2026-06-15T14:50:51-04:00","alt":"Westgate 180\/240\/300 Watt 120-277V Dynamic Beam Adjustable LED Extra Large Area Light 3000K\/4000K\/5000K Selectable Bronze","width":2000,"height":2000,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/files\/LAX-XL-180-300W-MCTPD-PSR_Main.webp?v=1781549451","variant_ids":[48645514920180]},"available":true,"name":"180\/240\/300 Watt 120-277V Dynamic Beam Adjustable LED Extra Large Area Light 3000K\/4000K\/5000K - Selectable \/ Bronze","public_title":"Selectable \/ Bronze","options":["Selectable","Bronze"],"price":71831,"weight":7874,"compare_at_price":null,"inventory_management":"shopify","barcode":"840378341240","featured_media":{"alt":"Westgate 180\/240\/300 Watt 120-277V Dynamic Beam Adjustable LED Extra Large Area Light 3000K\/4000K\/5000K Selectable Bronze","id":43879090880756,"position":4,"preview_image":{"aspect_ratio":1.0,"height":2000,"width":2000,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/files\/LAX-XL-180-300W-MCTPD-PSR_Main.webp?v=1781549451"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

{"id":48645514887412,"title":"Selectable \/ Black","option1":"Selectable","option2":"Black","option3":null,"sku":"LAX-XL-180-300W-MCTPD-PSR-BK","requires_shipping":true,"taxable":true,"featured_image":{"id":52853606187252,"product_id":9509062738164,"position":1,"created_at":"2026-06-15T14:50:30-04:00","updated_at":"2026-06-15T14:50:31-04:00","alt":"Westgate 180\/240\/300 Watt 120-277V Dynamic Beam Adjustable LED Extra Large Area Light 3000K\/4000K\/5000K Selectable Black","width":2000,"height":2000,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/files\/LAX-XL-180-300W-MCTPD-PSR-BK_Main.webp?v=1781549431","variant_ids":[48645514887412]},"available":true,"name":"180\/240\/300 Watt 120-277V Dynamic Beam Adjustable LED Extra Large Area Light 3000K\/4000K\/5000K - Selectable \/ Black","public_title":"Selectable \/ Black","options":["Selectable","Black"],"price":71831,"weight":7874,"compare_at_price":null,"inventory_management":"shopify","barcode":"840378341257","featured_media":{"alt":"Westgate 180\/240\/300 Watt 120-277V Dynamic Beam Adjustable LED Extra Large Area Light 3000K\/4000K\/5000K Selectable Black","id":43879083278580,"position":1,"preview_image":{"aspect_ratio":1.0,"height":2000,"width":2000,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/files\/LAX-XL-180-300W-MCTPD-PSR-BK_Main.webp?v=1781549431"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}

Details
Specifications
Documents
Request A Quote

Details

The Westgate LAX-XL-180-300W-MCTPD-PSR is a high-performance, compact LED area light engineered for demanding commercial and industrial outdoor environments. Designed as a versatile solution for parking lots, roadways, campuses, retail developments, industrial parks, and pedestrian pathways, this fixture delivers exceptional energy efficiency with an efficacy of up to 170 LM/W. Its selectable wattage (180/240/300 Watt) and selectable CCT (3000K/4000K/5000K) allow a single fixture to serve a wide range of project requirements, while the field-adjustable T2/T3/T4/T5 beam distribution optics provide precise photometric control without the need for multiple SKUs on hand.

On the electrical side, the fixture operates on 120–277VAC at 50/60Hz and features an integrated LED driver with 0–10V dimming capability and 10kV surge protection. The integrated 7-pin NEMA socket makes the fixture sensor-ready out of the box, supporting easy photocell and motion sensor integration for smart lighting control applications. The unit is rated for operating temperatures from -40°F to 122°F, ensuring reliable performance in extreme climates.

Mechanically, the LAX-XL-180-300W-MCTPD-PSR features a die-cast aluminum housing with an integrated heat sink for superior thermal management, and is IP65 rated for full wet location use. Its profile - measuring 34.21" x 12.82" x 3.15" with an EPA of 0.43 at 0° tilt - simplifies installation. The fixture is available in Black (LAX-XL-180-300W-MCTPD-PSR-BK) and Bronze (LAX-XL-180-300W-MCTPD-PSR) finishes.

Delivering lumen outputs of 30,600/40,800/51,000 lumens across its three wattage settings with a CRI of 80, this fixture provides consistent, high-quality illumination across all applications. It is DLC Premium listed and UL listed, meeting the compliance requirements for utility rebate programs and commercial specifications. Whether retrofitting HID fixtures or specifying new construction, the LAX-XL-180-300W-MCTPD-PSR offers the flexibility, durability, and performance that modern outdoor lighting projects demand.

Accessories (Sold Separately)
LAX XL Glare Shield
LAX Series Round-Pole Adapter

Specifications

Manufacturer	Westgate
Finish Color	Black	Bronze
MPN	LAX-XL-180-300W-MCTPD-PSR-BK	LAX-XL-180-300W-MCTPD-PSR
SKU	LAX-XL-180-300W-MCTPD-PSR-BK	LAX-XL-180-300W-MCTPD-PSR
UPC	840378341257	840378341240
DLC Product ID	S-LFHTTS
Lighting Technology	LED
Wattage	180/240/300 Watts
Voltage	120-277V
Surge Protection	10kV
Color Temperature (Kelvin)	3000/4000/5000K
Lumens	30,600/40,800/51,000 Lumens
Efficiency (Lumens Per Watt)	Up to 170 LPW
Dimmable	Yes, 0-10V Dimming
Beam Angle	Selectable T2/T3/T4/T5
CRI (Color Rendering Index)	80 CRI
Housing	Die-Cast Aluminum
Operating Temperature	-40°F to 122°F
Dimensions	34.21" L x 12.82" W x 3.15" H
Environment	Wet Location
Certifications	DLC Premium Listed, IP65 Rated, UL Listed
Warranty	5 Years

Documents

Westgate 180/24/300 Watt 120-277V Adjustable LED Area Light Specification Sheet

Westgate 180/240/300 Watt 120-277V Adjustable LED Area Light Installation Instructions

Westgate 180/240/300 Watt 120-277V Adjustable LED Area Light DLC Product Listing
