1x4 18/29/34 Watt 120-277V Back Lit LED Flat Panel 3500K/4000K/5000K

Day-Brite CFI SKU: 1SBP2035L8CS-4-UNV-DIM
  • Damp Location Rated, IC Rated, NSF Listed
/
Color Temp
  • Free Shipping on Orders Over $750 (contiguous US only)
  • Most in-stock items ship the same day!
  • Helping you maximize your green® since 2007!
Details

Day-Brite/CFI FluxPanel Selectable (SBP) is a highly versatile luminaire designed to provide three lumen and three CCT packages per size. Available for use in recessed, suspended, and surface mount applications, the SBP is a versatile luminaire that is ideal for general lighting applications such as open office, schools, healthcare, and retail.

This 1x4 Back Lit LED Flat Panel operates at 18/29/34 Watts across a universal 120-277V input and offers selectable color temperatures of 3500K, 4000K, and 5000K. It delivers nominal lumen outputs of 2400, 3500, and 4000 respectively, with 80 CRI and 0-10V dimming capability. The Day-Brite CFI part number is 1SBP2035L8CS-4-UNV-DIM.

The overall luminaire is 1-1/2" deep including the driver box, providing minimal intrusion into the plenum space. The die-formed driver box features a standard access plate for ease of wiring and offers tool-free access to drivers from above. Integral clips accommodate definitive attachment to T-bar grid for recessed applications, and even light distribution across the lens ensures exceptionally low glare, minimizing distractions at the ceiling plane.

Designed for use with standard Grid (NEMA "G") or Narrow Grid (NEMA "NFG") ceiling T-bars. Drywall or plaster applications require use with the FMA "F" mounting frame accessory, sold and shipped separately. The fixture carries a 5-year warranty and holds certifications including IC Rated, NSF, RoHS, and cULus.

Field installable accessories sold separately include an Emergency Driver Kit, 1x4 Mounting Frame, Selectable Suspension Kit (with and without power), and a 1x4 Surface Mount Kit.

Specifications
Manufacturer Day-Brite CFI
MPN 1SBP2035L8CS-4-UNV-DIM
SKU 1SBP2035L8CS-4-UNV-DIM
UPC 190096201198
Lighting Technology LED
Wattage 18/29/34 Watts
Voltage 120-277V
Color Temperature (Kelvin) 3500K/4000K/5000K
Lumens 2400/3500/4000 Lumens
Dimmable Yes, 0-10V Dimming
Rated Life 67,000 Hours
CRI (Color Rendering Index) 80 CRI
Minimum Start Temperature -20°C (-4°F)
Dimensions 47 3/4” L x 11 7/8” W x 1 1/4” H
Environment Suitable for Damp Locations
Certifications IC Rated, NSF, RoHS, cULus
Warranty 5 Years



Color Temperature (Kelvin) 3500K Bright White
Wattage 18 Watts 29 Watts 34 Watts
Lumens 2282 Lumens 3360 Lumens 3811 Lumens
Efficiency (Lumens Per Watt) 124 LPW 115 LPW 111 LPW
Color Temperature (Kelvin) 4000K Cool White
Wattage 18 Watts 28 Watts 33 Watts
Lumens 2417 Lumens 3632 Lumens 4033 Lumens
Efficiency (Lumens Per Watt) 135 LPW 129 LPW 123 LPW
Color Temperature (Kelvin) 5000K Daylight
Wattage 18 Watts 29 Watts 34 Watts
Lumens 2364 Lumens 3491 Lumens 3847 Lumens
Efficiency (Lumens Per Watt) 128 LPW 120 LPW 112 LPW
Documents

Day-Brite CFI 1x4 Back Lit LED Flat Panel Specification Sheet

Day-Brite CFI 1x4 Back Lit LED Flat Panel Installation Instructions
