21 Inch 7 Watt 700 Lumen Double Ended Ballast Bypass T5 LED Tube

Satco SKU: S11907
Satco 21 Inch 7 Watt 700 Lumen Double Ended Ballast Bypass T5 LED Tube 3000K Warm White
Satco 21 Inch 7 Watt 700 Lumen Double Ended Ballast Bypass T5 LED Tube

21 Inch 7 Watt 700 Lumen Double Ended Ballast Bypass T5 LED Tube

Satco SKU: S11907
  • Enclosed Fixture Rated, NSF Listed
Regular price $7.96
Color Temp
  • Free Shipping on Orders Over $750
  • Most in-stock items ship the same day!

Note: These tubes will not work with any existing fluorescent ballast. You MUST bypass your current ballast upon install.

Satco's Shatterproof LED T5 tubes feature shatterproof coated glass and frosted lens that eliminates pixilation. PET coating ensures no broken glass and it's ETL Sanitation Listed NSF/ANSI Standard 2 - Food Equipment approved. No ballast or driver needed for double-ended wiring ballast bypass. Get maximum utility rebates & maintenance savings.

Satco's 21" LED Mini Bi Pin G5 base ballast by-pass T5 LED Tubes offer 700 lumens, comparable to 13W fluorescent T5 systems. Consuming only 7W, these lamps are compatible with 120-277 line voltages and come in 3000K, 4000K, and 6500K color temperatures. NSF Certified, mercury-free, with instant on/off, these LED tubes are an ideal retrofit for 21" fluorescent tubes--perfect for under cabinet lighting.

This item is the Satco part number S1190X - 7W/LED/T5/8(XX)/BP - a replacement for your current F13T5 lamps. It is a double ended ballast bypass replacement for your current 21 inch mini T5 fluorescent lamps. Each lamp consumes just 7 watts of 120-277v input power - saving you 40% in energy costs! These T5 LED retrofit bulbs have a 240 degree beam angle, generate 700 lumens - That's an awesome 100 lumens per watt of 82 CRI light. They are NOT dimmable, measure .83" diameter by 20.91" in Maximum Overall Length (MOL) and are UL Listed - damp location rated. The Satco 7W LED tube comes in a frosted finish, each tube has a 50,000-hour lifetime and they carry a Five Year Warranty. Please NOTE: When retrofitting these LED tube lights to a fluorescent fixture, the ballast must be by-passed or removed from the fixture. Additionally, by-passing the ballast will ensure no RFI interference.

**Note: Though nominally referred to as a T5, this lamp has a T6 diameter. Please check the dimensions of your enclosed fixture before ordering.**

Manufacturer Satco
Color Temperature (Kelvin) 3000K Warm White 4000K Cool White 6500K Daylight
MPN 7W/LED/T5/830/BP 7W/LED/T5/840/BP 7W/LED/T5/850/BP
SKU S11907 S11908 S11909
UPC 045923119071 045923119088 045923119095
Lumens 700 Lumens
Efficiency (Lumens Per Watt) 100 LPW
Lighting Technology LED
Wattage 7 Watt
Voltage 120-277V
Frequency 50/60Hz
Ballast Operation Type B Bypass
Wiring Method Double Ended
Bulb Shape T5
Base G5 Mini Bi-Pin
Dimmable Non-Dimmable
Beam Angle 240 Degrees
Rated Life 50,000 Hours
CRI (Color Rendering Index) 82 CRI
Power Factor 0.9
Construction Shatter-Proof Glass
Lens Frosted
Fluorescent Equivalent 13 Watt
Operating Temperature −25ºC to 45ºC
Dimensions 20.91" MOL x 0.83" MOD
Certifications Title 20 Exempt, Title 24 Exempt, Enclosed Fixture Rated, NSF Listed
Environment Damp Location
Warranty 5 Year Limited
