Name: 2x2 20/25/30/40 Watt Selectable Architectural LED Grille Troffer 3500K/4000K/5000K
Brand: Westgate
SKU: LTRA-2X2-MCTP
Price: 84.46 USD
Availability: InStock

2x2 20/25/30/40 Watt Selectable Architectural LED Grille Troffer 3500K/4000K/5000K

Price

Color Temp

Selectable

Quantity

Free Shipping on Orders Over $750 (contiguous US only)

Most in-stock items ship the same day!

Helping you maximize your green® since 2007!

[{"id":47090467897588,"title":"Selectable","option1":"Selectable","option2":null,"option3":null,"sku":"LTRA-2X2-MCTP","requires_shipping":true,"taxable":true,"featured_image":{"id":49178855506164,"product_id":9178880934132,"position":1,"created_at":"2025-10-28T15:31:44-04:00","updated_at":"2025-10-28T15:31:45-04:00","alt":null,"width":800,"height":800,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/files\/Westgate_LTRA-2X2-MCTPHDpicture3.webp?v=1761679905","variant_ids":[47090467897588]},"available":true,"name":"2x2 20\/25\/30\/40 Watt Selectable Architectural LED Grille Troffer 3500K\/4000K\/5000K - Selectable","public_title":"Selectable","options":["Selectable"],"price":8446,"weight":4536,"compare_at_price":null,"inventory_management":"shopify","barcode":"840378315050","featured_media":{"alt":null,"id":40390788710644,"position":1,"preview_image":{"aspect_ratio":1.0,"height":800,"width":800,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/files\/Westgate_LTRA-2X2-MCTPHDpicture3.webp?v=1761679905"}},"requires_selling_plan":false,"selling_plan_allocations":[]}]

Details
Specifications
Documents
Request A Quote

Details

The Westgate Architectural Grille Troffer with wattage and CCT selectability offers customizable illumination for commercial and architectural spaces. A performance engineered optical lens assembly delivers unique beam angles and reduces glare, while the pure aluminum heat sinks offers heat transmission faster than die-cast steel. Featuring adjustable light output and color temperatures (3500K-5000K), it provides energy-efficient, versatile, and aesthetically pleasing lighting.

The 2x2 Westgate Architectural LED Grille Troffer offers versatile and efficient lighting with selectable wattage options (20W/25W/30W/40W), delivering 2,500–5,000 lumens at a high 125 lm/W efficiency. Featuring color temperature adjustability between 3500K, 4000K, and 5000K, this fixture allows easy customization to suit various indoor environments. Its 0–10V dimming capability provides smooth light control for enhanced comfort and energy savings. Designed exclusively for indoor use, the troffer boasts a 50,000-hour rated lifespan for long-lasting performance and comes backed by a reliable 5-year warranty, making it an excellent choice for commercial, educational, and office lighting applications.

Specifications

Manufacturer	Westgate
MPN	LTRA-2X4-MCTP
SKU	LTRA-2X4-MCTP
UPC	840378315050
Lighting Technology	LED
Wattage	20/25/30/40 Watts
Voltage	120-277V
Frequency	50/60Hz
Color Temperature (Kelvin)	3500K/4000K/5000K
Lumens	2500/3125/3750/5000 Lumens
Efficiency (Lumens Per Watt)	125 lm/W
Dimmable	Yes, 0-10V
Rated Life	50,000 Hours
CRI (Color Rendering Index)	>80
Power Factor	>0.92
Construction	Aluminum
Lens	Polycarbonate
Operating Temperature	-22°F to 104°F
Dimensions	1.62" D x 23.74" W x 23.74" H
Certifications	cULus, IP20
Environment	Indoor Only
BUG Rating	B2-U3-G2
Warranty	5 Year Warranty

Documents

Westgate Architectural LED Grille Troffer Specification Sheet
