3.5mm Pin LEDVANCE Link Bluetooth Mesh Low Voltage Controller

Sylvania Lighting SKU: 62630
/
  • Free Shipping on Orders Over $750 (contiguous US only)
  • Most in-stock items ship the same day!
  • Helping you maximize your green® since 2007!
Details

The Sylvania ADAPTERAUX12VBLE is a 3.5mm PIN LEDVANCE LINK™ Bluetooth® Mesh Low Voltage Controller that adds intelligent wireless lighting control to compatible 12VDC, 0-10V dimmable fixtures. Featuring a simple 3.5mm plug-in design, it installs quickly and is configured through the free LEDVANCE LINK™ app for iOS and Android, enabling secure Bluetooth® Mesh communication or the wireless wall controller.

Designed for flexible lighting management, the controller supports wireless grouping, zoning, scene creation, setting time-based scheduling, high- and low-end trim, and QR code-based Admin and Guest access. Built with robust cybersecurity features for reliable, always-on performance, it is rated for indoor use in temperatures from -22°F to 149°F (-30°C to +65°C), is cULus, RoHS, FCC, Bluetooth® Mesh, and DLC NLC 5.0 certified, and is backed by a 5-year warranty through the NLB Trusted Warranty Program.

Specifications
Manufacturer Sylvania Lighting
MPN ADAPTERAUX12VBLE
SKU 62630
UPC 0046135626302
Sensor Type Bluetooth Mesh Wireless Controller
Input Voltage 12Vdc ±0.5V
Input Current 41 ±5mA
Standby Power 0.5 ±0.1W
Dimmable Yes, 0-10V dimming
Radio Frequency Band 2.4GHz ±75MHz
Mesh Range 200ft max (clear line of sight)
Operating Temperature -22°F to 149°F (-30°C to 65°C), 5% – 85% RH
Dimensions- Controller 1.54" H x 1.08" Diameter
Dimensions- Back Plate 4.68" L x 2.95" W x 0.49" D
Environment Damp Location Rated
Certifications cULus, FCC, RoHS, DLC NLC Listed
Documents

Sylvania Bluetooth Mesh Low Voltage Controller Specification Sheet

Sylvania Bluetooth Mesh Low Voltage Controller Installation Instructions
