Name: 45/60/75 Watt 120-277V Selectable LED Full Cut Off Wall Pack 3000K/4000K/5000K
Brand: ZLED Lighting
SKU: ZL-WPFC-45-60-75-CCT-LH
Price: 153.86 USD
Availability: InStock

ZLED Lighting 45/60/75 Watt 120-277V Selectable LED Full Cut Off Wall Pack 3000K/4000K/5000K Selectable Bronze

ZLED Lighting 45/60/75 Watt 120-277V Selectable LED Full Cut Off Wall Pack 3000K/4000K/5000K

ETL Certified

Price

Color Temp

Selectable

Finish Color

Bronze

Quantity

Free Shipping on Orders Over $750 (contiguous US only)

Most in-stock items ship the same day!

Helping you maximize your green® since 2007!

[{"id":49051939143924,"title":"Selectable \/ Bronze","option1":"Selectable","option2":"Bronze","option3":null,"sku":"ZL-WPFC-45-60-75-CCT-LH","requires_shipping":true,"taxable":true,"featured_image":{"id":53510161989876,"product_id":9586002788596,"position":1,"created_at":"2026-07-30T16:57:25-04:00","updated_at":"2026-07-30T16:57:26-04:00","alt":"ZLED Lighting 45\/60\/75 Watt 120-277V Selectable LED Full Cut Off Wall Pack 3000K\/4000K\/5000K Selectable Bronze","width":1195,"height":631,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/files\/ZL-WPFC-45-60-75-CCT-LH.webp?v=1785445046","variant_ids":[49051939143924]},"available":true,"name":"45\/60\/75 Watt 120-277V Selectable LED Full Cut Off Wall Pack 3000K\/4000K\/5000K - Selectable \/ Bronze","public_title":"Selectable \/ Bronze","options":["Selectable","Bronze"],"price":15386,"weight":2127,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"featured_media":{"alt":"ZLED Lighting 45\/60\/75 Watt 120-277V Selectable LED Full Cut Off Wall Pack 3000K\/4000K\/5000K Selectable Bronze","id":44524161007860,"position":1,"preview_image":{"aspect_ratio":1.894,"height":631,"width":1195,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/files\/ZL-WPFC-45-60-75-CCT-LH.webp?v=1785445046"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

{"id":49051939143924,"title":"Selectable \/ Bronze","option1":"Selectable","option2":"Bronze","option3":null,"sku":"ZL-WPFC-45-60-75-CCT-LH","requires_shipping":true,"taxable":true,"featured_image":{"id":53510161989876,"product_id":9586002788596,"position":1,"created_at":"2026-07-30T16:57:25-04:00","updated_at":"2026-07-30T16:57:26-04:00","alt":"ZLED Lighting 45\/60\/75 Watt 120-277V Selectable LED Full Cut Off Wall Pack 3000K\/4000K\/5000K Selectable Bronze","width":1195,"height":631,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/files\/ZL-WPFC-45-60-75-CCT-LH.webp?v=1785445046","variant_ids":[49051939143924]},"available":true,"name":"45\/60\/75 Watt 120-277V Selectable LED Full Cut Off Wall Pack 3000K\/4000K\/5000K - Selectable \/ Bronze","public_title":"Selectable \/ Bronze","options":["Selectable","Bronze"],"price":15386,"weight":2127,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"featured_media":{"alt":"ZLED Lighting 45\/60\/75 Watt 120-277V Selectable LED Full Cut Off Wall Pack 3000K\/4000K\/5000K Selectable Bronze","id":44524161007860,"position":1,"preview_image":{"aspect_ratio":1.894,"height":631,"width":1195,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/files\/ZL-WPFC-45-60-75-CCT-LH.webp?v=1785445046"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}

Details
Specifications
Documents
Request A Quote

Details

The ZLED Lighting Full Cut-Off LED Wall Pack (ZL-WPFC-45-60-75-CCT-LH) delivers reliable, high-performance outdoor illumination for commercial and industrial applications. Designed to mount directly on building exteriors, this fixture provides focused, downward light distribution that minimizes light spill and reduces light pollution — making it an ideal choice for parking areas, building facades, entryways, walkways, and driveways.

With selectable wattage (45W/60W/75W) and selectable color temperature (3000K/4000K/5000K), this wall pack adapts to the specific brightness and ambiance requirements of any installation. Operating across a wide voltage range of 120–277V, it integrates seamlessly into virtually any commercial electrical system. At 127 lm/W efficacy and a rated lifespan of 50,000 hours, it significantly reduces both energy consumption and maintenance overhead compared to traditional HID or metal halide fixtures.

Built for demanding environments, the fixture is ETL Listed, Wet Location Rated, and operates reliably from -40°F to +104°F (-40°C to +40°C). It features 0–10V dimming capability, a Ra >70 CRI rating, and a 90° x 100° beam angle optimized for ground-level coverage at mounting heights of 14–16 ft. The fixed bracket mount and compact dimensions (12.60" × 7.48" × 5.12") make installation straightforward on most building surfaces. Backed by a 5-year warranty, this fixture is a dependable long-term investment for any outdoor lighting project.

Lumen Output (3000K): 45W — 5,715 lm | 60W — 7,620 lm | 75W — 9,534 lm

Specifications

Manufacturer	ZLED Lighting
MPN	ZL-WPFC-45-60-75-CCT-LH
SKU	ZL-WPFC-45-60-75-CCT-LH
Lighting Technology	LED
Wattage	45/60/75 Watts
Voltage	120-277V
Color Temperature (Kelvin)	3000K/4000K/5000K
Lumens @ 3000K	5,715/7,620/9,534 Lumens
Efficiency (Lumens Per Watt) @ 3000K	127 LPW
Dimmable	Yes, 0-10V
Beam Angle	90° x 100°
Rated Life	50,000 Hours
CRI (Color Rendering Index)	Ra>70 CRI
Finish Color	Bronze
Operating Temperature	-40º to 104ºF; -40º to 40º C
Dimensions	12.60” L x 5.12” W x 7.48” H
Environment	Wet Location
Certifications	ETL Listed
Warranty	5 Years

Documents

ZLED 45/60/75 Watt 120-277V Selectable LED Full Cut Off Wall Pack Specification Sheet
