55 Watt 120-277V Eagle Small LED Decorative Post Top
Atlas Lighting
SKU: EPT8L2UNV30K8BK
- Details
- Specifications
- 3000K Warm White
- 4000K Cool White
- 4500K Cool White
- 5000K Daylight
- Documents
- Request A Quote
Details
The Atlas Lighting Eagle Small LED Decorative Post Top combines elegant architectural styling with high performance LED illumination for pedestrian scale outdoor applications. Its rugged die-cast aluminum housing features stylish twin cast aluminum arms and a base designed to mount directly to 2-3/8 inch to 3 inch outer diameter tenons, while an optional flush mount adapter provides virtually seamless installation on 4 inch round poles. A large aperture lens with a dense LED array and visual comfort optics delivers bright, efficient illumination while maintaining a comfortable appearance, making it ideal for walkways, plazas, campuses, and other public spaces.
The Eagle Post Top produces 8,000 lumens from 55 watts and is available in 3000K warm white, 4000K cool white, 4500K cool white or 5000K daylight, with a universal 120-277V input and 0-10V dimming for flexible control. To ensure you get the light where you need, this decorative post top is available in 5 different distributions as well: Type 2, Type 3W Wide Throw, Type 4F Forward Throw, Type 5D Diffused and Type 5Q Square. Finishes include durable black, bronze, silver or white. Rated for 100,000 hours of service, this small decorative post top fixture is built to withstand demanding outdoor environments with a wet-location and IP66 rating. DLC Listed (most models) and backed by a 5 year limited warranty, the Eagle provides dependable, energy-efficient performance with sophisticated curb appeal.
Specifications
| Manufacturer | Atlas Lighting |
| Lighting Technology | LED |
| Wattage | 55 Watts |
| Voltage | 120-277V |
| Lumens | 8,000 Lumens |
| Efficiency (Lumens Per Watt) | 145 lm/W |
| Dimmable | Yes, 0-10V Dimming |
| Rated Life | 100,000 Hours |
| CRI (Color Rendering Index) | 80 CRI |
| Housing | Die-cast Aluminum |
| Lens | Diffused Lens |
| Mounting | Post Top, 2-3/8"-3" outer diameter Tenon |
| Operating Temperature | -40°C to +40°C (-40°F to +104°F) |
| Dimensions | Top: 16" Diameter, Base: 4" Diameter; 22.24" H |
| Environment | IP66 Rated, Wet Location |
| Certifications | cuLus, Made in USA, DLC Listed |
| Warranty | 5 Year Limited Warranty |
3000K Warm White
| Finish Color | Black | ||||
| Distribution | Type 2 | Type 3W | Type 4F | Type 5D | Type 5Q |
| MPN | EPT8L2UNV30K8BK | EPT8L3WUNV30K8BK | EPT8L4FUNV30K8BK | EPT8L5DUNV30K8BK | EPT8L5QUNV30K8BK |
| SKU | EPT8L2UNV30K8BK | EPT8L3WUNV30K8BK | EPT8L4FUNV30K8BK | EPT8L5DUNV30K8BK | EPT8L5QUNV30K8BK |
| UPC | 765364077975 | 765364077975 | 765364077975 | 765364077975 | 765364077975 |
| DLC Product ID | N/A | S-KZLFSN | S-5TTQKS | S-TG2P2W | S-28P0M9 |
| Finish Color | Bronze | ||||
| Distribution | Type 2 | Type 3W | Type 4F | Type 5D | Type 5Q |
| MPN | EPT8L2UNV30K8BZA | EPT8L3WUNV30K8BZA | EPT8L4FUNV30K8BZA | EPT8L4FUNV30K8BZA | EPT8L4FUNV30K8BZA |
| SKU | EPT8L2UNV30K8BZA | EPT8L3WUNV30K8BZA | EPT8L4FUNV30K8BZA | EPT8L4FUNV30K8BZA | EPT8L4FUNV30K8BZA |
| UPC | 765364077975 | 765364077975 | 765364077975 | 765364077975 | 765364077975 |
| DLC Product ID | N/A | S-KZLFSN | S-5TTQKS | S-TG2P2W | S-28P0M9 |
| Finish Color | Silver | ||||
| Distribution | Type 2 | Type 3W | Type 4F | Type 5D | Type 5Q |
| MPN | EPT8L2UNV30K8SL | EPT8L3WUNV30K8SL | EPT8L4FUNV30K8SL | EPT8L5DUNV30K8SL | EPT8L5QUNV30K8SL |
| SKU | EPT8L2UNV30K8SL | EPT8L3WUNV30K8SL | EPT8L4FUNV30K8SL | EPT8L5DUNV30K8SL | EPT8L5QUNV30K8SL |
| UPC | 765364077975 | 765364077975 | 765364077975 | 765364077975 | 765364077975 |
| DLC Product ID | N/A | S-KZLFSN | S-5TTQKS | S-TG2P2W | S-28P0M9 |
| Finish Color | White | ||||
| Distribution | Type 2 | Type 3W | Type 4F | Type 5D | Type 5Q |
| MPN | EPT8L2UNV30K8WT | EPT8L3WUNV30K8WT | EPT8L4FUNV30K8WT | EPT8L5DUNV30K8WT | EPT8L5QUNV30K8WT |
| SKU | EPT8L2UNV30K8WT | EPT8L3WUNV30K8WT | EPT8L4FUNV30K8WT | EPT8L5DUNV30K8WT | EPT8L5QUNV30K8WT |
| UPC | 765364077975 | 765364077975 | 765364077975 | 765364077975 | 765364077975 |
| DLC Product ID | N/A | S-KZLFSN | S-5TTQKS | S-TG2P2W | S-28P0M9 |
4000K Cool White
| Finish Color | Black | ||||
| Distribution | Type 2 | Type 3W | Type 4F | Type 5D | Type 5Q |
| MPN | EPT8L2UNV40K8BK | EPT8L3WUNV40K8BK | EPT8L4FUNV40K8BK | EPT8L5DUNV40K8BK | EPT8L5QUNV40K8BK |
| SKU | EPT8L2UNV40K8BK | EPT8L3WUNV40K8BK | EPT8L4FUNV40K8BK | EPT8L5DUNV40K8BK | EPT8L5QUNV40K8BK |
| UPC | 765364077975 | 765364077975 | 765364077975 | 765364077975 | 765364077975 |
| DLC Product ID | N/A | S-Z4DB4L | S-B0MDN3 | S-63309K | S-CWXSZN |
| Finish Color | Bronze | ||||
| Distribution | Type 2 | Type 3W | Type 4F | Type 5D | Type 5Q |
| MPN | EPT8L2UNV40K8BZA | EPT8L3WUNV40K8BZA | EPT8L4FUNV40K8BZA | EPT8L5DUNV40K8BZA | EPT8L5QUNV40K8BZA |
| SKU | EPT8L2UNV40K8BZA | EPT8L3WUNV40K8BZA | EPT8L4FUNV40K8BZA | EPT8L5DUNV40K8BZA | EPT8L5QUNV40K8BZA |
| UPC | 765364077975 | 765364077975 | 765364077975 | 765364077975 | 765364077975 |
| DLC Product ID | N/A | S-Z4DB4L | S-B0MDN3 | S-63309K | S-CWXSZN |
| Finish Color | Silver | ||||
| Distribution | Type 2 | Type 3W | Type 4F | Type 5D | Type 5Q |
| MPN | EPT8L2UNV40K8SL | EPT8L3WUNV40K8SL | EPT8L4FUNV40K8SL | EPT8L5DUNV40K8SL | EPT8L5QUNV40K8SL |
| SKU | EPT8L2UNV40K8SL | EPT8L3WUNV40K8SL | EPT8L4FUNV40K8SL | EPT8L5DUNV40K8SL | EPT8L5QUNV40K8SL |
| UPC | 765364077975 | 765364077975 | 765364077975 | 765364077975 | 765364077975 |
| DLC Product ID | N/A | S-Z4DB4L | S-B0MDN3 | S-63309K | S-CWXSZN |
| Finish Color | White | ||||
| Distribution | Type 2 | Type 3W | Type 4F | Type 5D | Type 5Q |
| MPN | EPT8L2UNV40K8WT | EPT8L3WUNV40K8WT | EPT8L4FUNV40K8WT | EPT8L5DUNV40K8WT | EPT8L5QUNV40K8WT |
| SKU | EPT8L2UNV40K8WT | EPT8L3WUNV40K8WT | EPT8L4FUNV40K8WT | EPT8L5DUNV40K8WT | EPT8L5QUNV40K8WT |
| UPC | 765364077975 | 765364077975 | 765364077975 | 765364077975 | 765364077975 |
| DLC Product ID | N/A | S-Z4DB4L | S-B0MDN3 | S-63309K | S-CWXSZN |
4500K Cool White
| Finish Color | Black | ||||
| Distribution | Type 2 | Type 3W | Type 4F | Type 5D | Type 5Q |
| MPN | EPT8L2UNV45K8BK | EPT8L3WUNV45K8BK | EPT8L4FUNV45K8BK | EPT8L5DUNV45K8BK | EPT8L5QUNV45K8BK |
| SKU | EPT8L2UNV45K8BK | EPT8L3WUNV45K8BK | EPT8L4FUNV45K8BK | EPT8L5DUNV45K8BK | EPT8L5QUNV45K8BK |
| UPC | 765364077975 | 765364077975 | 765364077975 | 765364077975 | 765364077975 |
| DLC Product ID | N/A | N/A | N/A | S-BSYZFQ | N/A |
| Finish Color | Bronze | ||||
| Distribution | Type 2 | Type 3W | Type 4F | Type 5D | Type 5Q |
| MPN | EPT8L2UNV45K8BZA | EPT8L3WUNV45K8BZA | EPT8L4FUNV45K8BZA | EPT8L5DUNV45K8BZA | EPT8L5QUNV45K8BZA |
| SKU | EPT8L2UNV45K8BZA | EPT8L3WUNV45K8BZA | EPT8L4FUNV45K8BZA | EPT8L5DUNV45K8BZA | EPT8L5QUNV45K8BZA |
| UPC | 765364077975 | 765364077975 | 765364077975 | 765364077975 | 765364077975 |
| DLC Product ID | N/A | N/A | N/A | S-BSYZFQ | N/A |
| Finish Color | Silver | ||||
| Distribution | Type 2 | Type 3W | Type 4F | Type 5D | Type 5Q |
| MPN | EPT8L2UNV45K8SL | EPT8L3WUNV45K8SL | EPT8L4FUNV45K8SL | EPT8L5DUNV45K8SL | EPT8L5QUNV45K8SL |
| SKU | EPT8L2UNV45K8SL | EPT8L3WUNV45K8SL | EPT8L4FUNV45K8SL | EPT8L5DUNV45K8SL | EPT8L5QUNV45K8SL |
| UPC | 765364077975 | 765364077975 | 765364077975 | 765364077975 | 765364077975 |
| DLC Product ID | N/A | N/A | N/A | S-BSYZFQ | N/A |
| Finish Color | White | ||||
| Distribution | Type 2 | Type 3W | Type 4F | Type 5D | Type 5Q |
| MPN | EPT8L2UNV45K8WT | EPT8L3WUNV45K8WT | EPT8L4FUNV45K8WT | EPT8L4FUNV45K8WT | EPT8L5QUNV45K8WT |
| SKU | EPT8L2UNV45K8WT | EPT8L3WUNV45K8WT | EPT8L4FUNV45K8WT | EPT8L4FUNV45K8WT | EPT8L5QUNV45K8WT |
| UPC | 765364077975 | 765364077975 | 765364077975 | 765364077975 | 765364077975 |
| DLC Product ID | N/A | N/A | N/A | S-BSYZFQ | N/A |
5000K Daylight
| Finish Color | Black | ||||
| Distribution | Type 2 | Type 3W | Type 4F | Type 5D | Type 5Q |
| MPN | EPT8L2UNV50K8BK | EPT8L3WUNV50K8BK | EPT8L4FUNV50K8BK | EPT8L5DUNV50K8BK | EPT8L5QUNV50K8BK |
| SKU | EPT8L2UNV50K8BK | EPT8L3WUNV50K8BK | EPT8L4FUNV50K8BK | EPT8L5DUNV50K8BK | EPT8L5QUNV50K8BK |
| UPC | 765364077975 | 765364077975 | 765364077975 | 765364077975 | 765364077975 |
| DLC Product ID | N/A | S-LSFBPF | S-56F7Y1 | S-LSFBPF | S-S2XPP1 |
| Finish Color | Bronze | ||||
| Distribution | Type 2 | Type 3W | Type 4F | Type 5D | Type 5Q |
| MPN | EPT8L2UNV50K8BZA | EPT8L3WUNV50K8BZA | EPT8L4FUNV50K8BZA | EPT8L5DUNV50K8BZA | EPT8L5QUNV50K8BZA |
| SKU | EPT8L2UNV50K8BZA | EPT8L3WUNV50K8BZA | EPT8L4FUNV50K8BZA | EPT8L5DUNV50K8BZA | EPT8L5QUNV50K8BZA |
| UPC | 765364077975 | 765364077975 | 765364077975 | 765364077975 | 765364077975 |
| DLC Product ID | N/A | S-LSFBPF | S-56F7Y1 | S-LSFBPF | S-S2XPP1 |
| Finish Color | Silver | ||||
| Distribution | Type 2 | Type 3W | Type 4F | Type 5D | Type 5Q |
| MPN | EPT8L2UNV50K8SL | EPT8L3WUNV50K8SL | EPT8L4FUNV50K8SL | EPT8L5DUNV50K8SL | EPT8L5QUNV50K8SL |
| SKU | EPT8L2UNV50K8SL | EPT8L3WUNV50K8SL | EPT8L4FUNV50K8SL | EPT8L5DUNV50K8SL | EPT8L5QUNV50K8SL |
| UPC | 765364077975 | 765364077975 | 765364077975 | 765364077975 | 765364077975 |
| DLC Product ID | N/A | S-LSFBPF | S-56F7Y1 | S-LSFBPF | S-S2XPP1 |
| Finish Color | White | ||||
| Distribution | Type 2 | Type 3W | Type 4F | Type 5D | Type 5Q |
| MPN | EPT8L2UNV50K8WT | EPT8L3WUNV50K8WT | EPT8L4FUNV50K8WT | EPT8L5DUNV50K8WT | EPT8L5QUNV50K8WT |
| SKU | EPT8L2UNV50K8WT | EPT8L3WUNV50K8WT | EPT8L4FUNV50K8WT | EPT8L5DUNV50K8WT | EPT8L5QUNV50K8WT |
| UPC | 765364077975 | 765364077975 | 765364077975 | 765364077975 | 765364077975 |
| DLC Product ID | N/A | S-LSFBPF | S-56F7Y1 | S-LSFBPF | S-S2XPP1 |
Documents
Atlas Lighting Eagle Small LED Decorative Post Top Specification Sheet
Atlas Lighting Eagle Small LED Decorative Post Top Installation Instructions
Atlas Lighting Eagle Small LED Decorative Post Top DLC Product Listing - 3000K Warm White Type 3W
Atlas Lighting Eagle Small LED Decorative Post Top DLC Product Listing - 3000K Warm White Type 4F
Atlas Lighting Eagle Small LED Decorative Post Top DLC Product Listing - 3000K Warm White Type 5D
Atlas Lighting Eagle Small LED Decorative Post Top DLC Product Listing - 3000K Warm White Type 5Q
Atlas Lighting Eagle Small LED Decorative Post Top DLC Product Listing - 4000K Cool White Type 3W
Atlas Lighting Eagle Small LED Decorative Post Top DLC Product Listing - 4000K Cool White Type 4F
Atlas Lighting Eagle Small LED Decorative Post Top DLC Product Listing - 4000K Cool White Type 5D
Atlas Lighting Eagle Small LED Decorative Post Top DLC Product Listing - 4000K Cool White Type 5Q
Atlas Lighting Eagle Small LED Decorative Post Top DLC Product Listing - 4500K Cool White Type 5D
Atlas Lighting Eagle Small LED Decorative Post Top DLC Product Listing - 5000K Daylight Type 3W
Atlas Lighting Eagle Small LED Decorative Post Top DLC Product Listing - 5000K Daylight Type 4F
Atlas Lighting Eagle Small LED Decorative Post Top DLC Product Listing - 5000K Daylight Type 5D
Atlas Lighting Eagle Small LED Decorative Post Top DLC Product Listing - 5000K Daylight Type 5Q
