70-85-100 Watt LED Integrated Bypass Photocell Low Profile Wall Pack 3000K/4000K/5000K

Satco SKU: 65-885
70-85-100 Watt LED Integrated Bypass Photocell Low Profile Wall Pack 3000K/4000K/5000K
70-85-100 Watt LED Integrated Bypass Photocell Low Profile Wall Pack 3000K/4000K/5000K
70-85-100 Watt LED Integrated Bypass Photocell Low Profile Wall Pack 3000K/4000K/5000K
70-85-100 Watt LED Integrated Bypass Photocell Low Profile Wall Pack 3000K/4000K/5000K
70-85-100 Watt LED Integrated Bypass Photocell Low Profile Wall Pack 3000K/4000K/5000K
70-85-100 Watt LED Integrated Bypass Photocell Low Profile Wall Pack 3000K/4000K/5000K
70-85-100 Watt LED Integrated Bypass Photocell Low Profile Wall Pack 3000K/4000K/5000K
70-85-100 Watt LED Integrated Bypass Photocell Low Profile Wall Pack 3000K/4000K/5000K

70-85-100 Watt LED Integrated Bypass Photocell Low Profile Wall Pack 3000K/4000K/5000K

Satco SKU: 65-885
  • DLC Premium Listed, IP65, Wet Location Rated
/
Color Temp
  • Free Shipping on Orders Over $750 (contiguous US only)
  • Most in-stock items ship the same day!
  • Helping you maximize your green® since 2007!
Details

SATCO|NUVO’s LED Low Profile Wall Packs offer field-selectable settings, allowing you to tailor the wattage and color temperature to your needs. The sleek low-profile design features a durable IK08 vandal resistant lens to ensure a clean look and long-lasting durability. Added features include 0-10V dimming, an IP65 rating, and an integrated photocell that can easily be bypassed with the convenient on/off switch. New EM integrated models are now available, offering up to 90 minutes of emergency runtime for added protection during power loss.

The DLC Listed 65-885 is Satco Lighting's color temperature and wattage selectable LED wall pack that consumes 70/85/100 watts of the universal 120-277 voltage. These selectable watts produce between 8817-12,941 lumens of either 3000K bright white, 4000K cool white or 5000K daylight, with a total CRI of 80. The wall packs also have integrated by-passable photocells. With a glass lens and die cast aluminum bronze finish, these fixtures are suitable for wet locations (IP65 Rated), have a 50,000-hour rated life, and feature a 5 year limited warranty.

Specifications
Manufacturer Satco
Finish Color Bronze
MPN 65-885
SKU 65-885
UPC 045923561030
DLC Product ID S-3MA72N
Lighting Technology LED
Wattage 70/85/100 Watts
Voltage 120-277V
Power Factor >0.9
Frequency 50/60Hz
Color Temperature (Kelvin) 3000K/4000K/5000K
Lumens 8817-12,941 Lumens
Efficiency (Lumens Per Watt) 129 LPW
Dimmable Yes, 0-10V Dimmable Down to 10%
Beam Angle 90 Degrees
Rated Life 50,000 Hours
CRI (Color Rendering Index) 80 CRI
Surge Protection 4kV
Mounting Wall Mount
Housing Die-Cast Aluminum
Lens Borosilicate Glass
Operating Temperature -40°C (-40°F) to 50°C (122°F)
Dimensions 15.55" L x 4.21" W x 9.76" H
Certifications DLC Premium Listed, FCC, ETL, RoHS, IP65
Environment Wet Location Rated
Warranty 5 Year Warranty
Documents

Satco Low Profile LED Wall Pack Specification Sheet

Satco Low Profile LED Wall Pack Installation Instructions

Satco Low Profile LED Wall Pack DLC Product Listing
