Get the best LED drivers from Magnitude Lighting and experience their advanced technology that produces the highest efficiency ratings in the industry. With headquarters in Orange County, they provide top-quality products, fast fulfillment, and top-notch customer support.
Magnitude Lighting brings you their E-Series voltage dimmable Class 2 LED Drivers. These LED Drivers are class 2 rated and able to operate at low temperatures with an efficiency of 90% and higher. This driver is dimmable and encased in a low profile aluminum enclosure, making it the perfect choice for under cabinet lights, tape lights, and various LED fixtures. These drivers have a wide range of wattages and current outputs to meet numerous applications. The Magnitude magnetic LED drivers are compact in size, allowing them to fit into your application.
The E40L12DC-KO low voltage LED driver by Magnitude Lighting, with a 40 watt maximum output power and 3.5A output current, is a reliable choice for constant voltage input (12V) LED systems. This dimmable driver is equipped with Auto Reset, over current, and short circuit protection, and has a universal input voltage of 120VAC. Additionally, it is NEMA 3R, UL Listed, and FCC 15 Part 2 compliant, while providing a 5-year warranty for added peace of mind. This LED Driver is dimmable with any standard MLV/incandescent TRIAC - (Leading edge) dimmer switch.
| Manufacturer | Magnitude Lighting |
| MPN | E40L12DC-KO |
| SKU | E40L12DC-KO |
| UPC | 810020791624 |
| Lighting Technology | LED |
| Driver | Constant Voltage |
| Output Current | 3.5A (3500mA) |
| Input Current | 0.41A |
| Output Wattage | 40 Watt |
| Input Voltage | 120VAC |
| Output Voltage | 12VDC |
| Frequency | 50/60Hz |
| Power Factor | >.95 |
| Efficiency | 90% |
| Dimming | Phase Dimming |
| Operating Temperature | -30°C to 65°C |
| Dimensions | 4.92" L x 1.97" W x 0.77" H |
| Certifications | Class 2, UL Listed, FCC 15 Part 2 |
| Environment | NEMA 3R |
| Warranty | 5 Year |
