20/30/35 Watt 2x2 Selectable LED Back-Lit Flat Panel 3500/4000/5000K

Morris Products SKU: 71164D
Morris Products 20/30/35 Watt 2x2 Selectable LED Back-Lit Flat Panel 3500/4000/5000K Selectable

20/30/35 Watt 2x2 Selectable LED Back-Lit Flat Panel 3500/4000/5000K

Morris Products SKU: 71164D
  • DLC Listed
Regular price $44.35
/
Color Temp
  • Free Shipping on Orders Over $750
  • Most in-stock items ship the same day!
  • Helping you maximize your green® since 2007!

The 20/30/35 Watt 2x2 LED Backlit Flat Panel Lighting Fixture is an ideal lighting fixture for new construction or replacing existing troffers in commercial and institutional settings. Featuring a polystyrene lens, steel backplate, and aluminum frame, it is DLC listed and IP20 rated for reliability and safety. With an estimated 50,000 hours of life expectancy, this Gen 4 selectable backlit flat panel is a cost-effective lighting solution.

This Morris 2x2 selectable backlit flat panel consumes 20/30/35 watts of 120-277 volt energy. They generate 2,700-4,520 lumens based on your choice of either 3500K bright white, 4000K cool white or 5000K daylight. This DLC listed selectable flat panel carries a 5 year warranty.

Manufacturer Morris Products
MPN 71164D
SKU 71164D
UPC 601986711647
Lighting Technology LED
Voltage Universal 120-277V
Frequency 60Hz
Dimmable Yes, 0-10V
Beam Angle 120 Degrees
Rated Life 50,000 Hours L70
CRI (Color Rendering Index) 83 CRI
Power Factor 0.9
Housing Aluminum
Lens Polystyrene Lens
Operating Temperature -13°F to 104° F
Dimensions 24" x 24" x 1.48"
Certifications DLC Listed, ETL Listed
DLC Product ID S-B0KAS6
Environment Dry Location
Warranty 5 Year Standard


Wattage 20 Watts
Color Temperature (Kelvin) 3500K Bright White 4000K Cool White 5000K Daylight
Lumens 2,700 Lumens 2,820 Lumens 2,720 Lumens
Efficiency (Lumens Per Watt) 135 LPW 141 LPW 136 LPW


Wattage 30 Watts
Color Temperature (Kelvin) 3500K Bright White 4000K Cool White 5000K Daylight
Lumens 3,840 Lumens 4,020 Lumens 3,870 Lumens
Efficiency (Lumens Per Watt) 128 LPW 134 LPW 129 LPW


Wattage 35 Watts
Color Temperature (Kelvin) 3500K Bright White 4000K Cool White 5000K Daylight
Lumens 4,313 Lumens 4,520 Lumens 4,354 Lumens
Efficiency (Lumens Per Watt) 123 LPW 129 LPW 124 LPW
