Name: 2x4 20/25/30 Wattage Selectable 120-277V LED Backlit Flat Panel 4000K
Brand: EiKO
SKU: 13173
Price: 90.78 USD
Availability: InStock

EiKO 2x4 20/25/30 Wattage Selectable 120-277V LED Backlit Flat Panel 4000K 4000K Cool White

EiKO 2x4 20/25/30 Wattage Selectable 120-277V LED Backlit Flat Panel 4000K

DLC Listed

Price

Color Temp

4000K Cool White

Quantity

Please call to confirm availability.

Free Shipping on Orders Over $750

Most in-stock items ship the same day!

[{"id":43893273952500,"title":"4000K Cool White","option1":"4000K Cool White","option2":null,"option3":null,"sku":"13173","requires_shipping":true,"taxable":true,"featured_image":{"id":39416302764276,"product_id":8087455203572,"position":1,"created_at":"2023-04-17T11:56:05-04:00","updated_at":"2023-04-17T11:56:05-04:00","alt":"EiKO 2x4 20\/25\/30 Wattage Selectable 120-277V LED Backlit Flat Panel 4000K 4000K Cool White  ","width":1200,"height":1200,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/products\/BP1-2230S-40-U_01_9df75214-0759-45a5-8ef1-8fa82a536ea6.png?v=1681746965","variant_ids":[43893273952500]},"available":true,"name":"2x4 20\/25\/30 Wattage Selectable 120-277V LED Backlit Flat Panel 4000K - 4000K Cool White","public_title":"4000K Cool White","options":["4000K Cool White"],"price":9078,"weight":3629,"compare_at_price":null,"inventory_management":"shopify","barcode":"031293131737","featured_media":{"alt":"EiKO 2x4 20\/25\/30 Wattage Selectable 120-277V LED Backlit Flat Panel 4000K 4000K Cool White  ","id":32010435985652,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1200,"width":1200,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/products\/BP1-2230S-40-U_01_9df75214-0759-45a5-8ef1-8fa82a536ea6.png?v=1681746965"}},"requires_selling_plan":false,"selling_plan_allocations":[]}]

Details
Specifications
Documents
Request A Quote

Details

The EiKO LED flat panel are designed for superior backlighting, with its LED arrangement across the entire panel. This efficient design requires no light guide plate, making it lightweight and resilient, even when hung. With 4 knockouts and a 6” junction box for easy access, plus seismic clips for quick installation, this is the perfect light for quick and easy flat panel installation.

This 2x4 wattage selectable 20/25/30 watt 120-277V LED backlit flat panel, part number BP1-24PS30P-40-U (13173), is perfect for shallow plenum spaces. Featuring a backlit design that provides direct light without a light guide plate, a high quality PMMA diffuse lens, and a lightweight design, this panel is easy and fast to install. With 2,500/3,125/3,750 lumens and a 4000K cool white color temperature, you'll get an impressive 125 lumens per watt. It also features 0-10V dimming and a 5 year limited warranty.

Specifications

Manufacturer	EiKO
MPN	BP1-24PS30P-40-U
SKU	13173
UPC	031293131737
Lighting Technology	LED
Voltage	120-277V
Color Temperature (Kelvin)	4000K Cool White
Wattage	20 Watt	25 Watt	30 Watt
Lumens	2,500 Lumens	3,125 Lumens	3,750 Lumens
Efficiency (Lumens Per Watt)	125 LPW
Dimmable	0-10V Dimming
Beam Angle	120 Degrees
Rated Life	50,000 Hours
CRI (Color Rendering Index)	80 CRI
Power Factor	>0.9
THD (Total Harmonic Distortion)	<20%
Construction	White Powder Coated Aluminum
Lens	Non-yellowing PMMA Diffusing
Fluorescent Equivalent	4 x 32 Watt 4FT T8
Operating Temperature	-20°C to 40°C
Dimensions	47 3/4" L x 23 3/4" W x 1 13/16" H
Certifications	DLC Listed, RoHS Compliant, FCC Compliant, ETL Listed
DLC Product ID	S-OD6MLY
Environment	Damp Location
Warranty	5 Year Limited

Documents

EiKO Wattage Selectable LED Backlit Flat Panel Specification Sheet

EiKO Wattage Selectable LED Backlit Flat Panel Installation Instructions

EiKO Wattage Selectable LED Backlit Flat Panel DLC Product Listing
