High Intensity Discharge (HID) lamps require a ballast to apply starting voltage to the lamp and establish current flow an arc between the lamp electrodes. Without a ballast, the arc will extinguish or draw increasing current until some circuit element burns up. Ballasts provide system stability by limiting the current that can be drawn.

Replacement F-Can ballasts are used primarily for indoor downlighting applications where quiet operation is required. All the components of these ballasts are enclosed in a fluorescent-style ballast can and are thermally protected.

Keystone Ballast MH-100X-D-FCAN, Replacement F-Can HID Ballast Kit for 100 Watt Metal Halide. This F Can ballast is designed with Circuit Type HX-HPF, for one 100W Metal Halide Lamp Type, M90 ANSI Ballast Type, 122 Input Watts, 120/277 Input Voltage, 60 Hz. The maximum distance this F Can ballast can be mounted from your 100 watt metal halide bulb is 10 feet. It has -30C minimum start temperature, UL temperature code of A and an insulation class of 180C. The physical dimensions of this F-Can ballast are 11.08" Long x 3.23" Wide x 2.75" High with 11.40" mounting dimensions and 12-14" leads. Please verify all dimensions for your application as these dimensions may vary by manufacturer. This Keystone Ballast carries a 2 year warranty.

A ballast, like any other electrical device, generates heat during normal operation. Excessive temperature will have an adverse effect on ballast life. Normal temperature limits for Universal F-Can Ballasts have a maximum case temperature of 90°C. For proper installation, insure that remote ballasts are properly vented and mounted to a heat-dissipating surface. Ballasts in metallic casings must always be grounded.

Specification Sheet
