Westgate 5/10/20/30 Watt 120-277V LED Non-Cutoff Bronze Wall Pack With 120V Photocell 3000K Warm White

Westgate 5/10/20/30 Watt 120-277V LED Non-Cutoff Bronze Wall Pack With 120V Photocell

DLC Listed, IP54

Price

Color Temperature

3000K Warm White

4000K Cool White

5000K Daylight

Quantity

Free Shipping on Orders Over $750

Most in-stock items ship the same day!

Helping you maximize your green® since 2007!

[{"id":46749789749492,"title":"3000K Warm White","option1":"3000K Warm White","option2":null,"option3":null,"sku":"LSWX-5-30W-30K-PC","requires_shipping":true,"taxable":true,"featured_image":{"id":48282401145076,"product_id":9104646406388,"position":1,"created_at":"2025-08-07T12:30:07-04:00","updated_at":"2025-08-07T12:30:08-04:00","alt":"Westgate 5\/10\/20\/30 Watt 120-277V LED Non-Cutoff Bronze Wall Pack With 120V Photocell 3000K Warm White","width":800,"height":800,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/files\/Westgate_LSWX-5-30W-BR_Front_Image.webp?v=1754584208","variant_ids":[46749789749492,46749789782260,46749789815028]},"available":true,"name":"5\/10\/20\/30 Watt 120-277V LED Non-Cutoff Bronze Wall Pack With 120V Photocell - 3000K Warm White","public_title":"3000K Warm White","options":["3000K Warm White"],"price":6446,"weight":1814,"compare_at_price":null,"inventory_management":"shopify","barcode":"845060073027","featured_media":{"alt":"Westgate 5\/10\/20\/30 Watt 120-277V LED Non-Cutoff Bronze Wall Pack With 120V Photocell 3000K Warm White","id":39617982726388,"position":1,"preview_image":{"aspect_ratio":1.0,"height":800,"width":800,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/files\/Westgate_LSWX-5-30W-BR_Front_Image.webp?v=1754584208"}},"requires_selling_plan":false,"selling_plan_allocations":[]},{"id":46749789782260,"title":"4000K Cool White","option1":"4000K Cool White","option2":null,"option3":null,"sku":"LSWX-5-30W-40K-PC","requires_shipping":true,"taxable":true,"featured_image":{"id":48282401145076,"product_id":9104646406388,"position":1,"created_at":"2025-08-07T12:30:07-04:00","updated_at":"2025-08-07T12:30:08-04:00","alt":"Westgate 5\/10\/20\/30 Watt 120-277V LED Non-Cutoff Bronze Wall Pack With 120V Photocell 3000K Warm White","width":800,"height":800,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/files\/Westgate_LSWX-5-30W-BR_Front_Image.webp?v=1754584208","variant_ids":[46749789749492,46749789782260,46749789815028]},"available":true,"name":"5\/10\/20\/30 Watt 120-277V LED Non-Cutoff Bronze Wall Pack With 120V Photocell - 4000K Cool White","public_title":"4000K Cool White","options":["4000K Cool White"],"price":6446,"weight":1814,"compare_at_price":null,"inventory_management":"shopify","barcode":"845060074253","featured_media":{"alt":"Westgate 5\/10\/20\/30 Watt 120-277V LED Non-Cutoff Bronze Wall Pack With 120V Photocell 3000K Warm White","id":39617982726388,"position":1,"preview_image":{"aspect_ratio":1.0,"height":800,"width":800,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/files\/Westgate_LSWX-5-30W-BR_Front_Image.webp?v=1754584208"}},"requires_selling_plan":false,"selling_plan_allocations":[]},{"id":46749789815028,"title":"5000K Daylight","option1":"5000K Daylight","option2":null,"option3":null,"sku":"LSWX-5-30W-50K-PC","requires_shipping":true,"taxable":true,"featured_image":{"id":48282401145076,"product_id":9104646406388,"position":1,"created_at":"2025-08-07T12:30:07-04:00","updated_at":"2025-08-07T12:30:08-04:00","alt":"Westgate 5\/10\/20\/30 Watt 120-277V LED Non-Cutoff Bronze Wall Pack With 120V Photocell 3000K Warm White","width":800,"height":800,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/files\/Westgate_LSWX-5-30W-BR_Front_Image.webp?v=1754584208","variant_ids":[46749789749492,46749789782260,46749789815028]},"available":true,"name":"5\/10\/20\/30 Watt 120-277V LED Non-Cutoff Bronze Wall Pack With 120V Photocell - 5000K Daylight","public_title":"5000K Daylight","options":["5000K Daylight"],"price":6446,"weight":1814,"compare_at_price":null,"inventory_management":"shopify","barcode":"845060073010","featured_media":{"alt":"Westgate 5\/10\/20\/30 Watt 120-277V LED Non-Cutoff Bronze Wall Pack With 120V Photocell 3000K Warm White","id":39617982726388,"position":1,"preview_image":{"aspect_ratio":1.0,"height":800,"width":800,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/files\/Westgate_LSWX-5-30W-BR_Front_Image.webp?v=1754584208"}},"requires_selling_plan":false,"selling_plan_allocations":[]}]

Details
Specifications
Documents
Request A Quote

Details

Westgate's LSWX Series LED Non-Cutoff Wall Pack has selectable 5/10/20/30 watts of power that generates 600-660/1,350-1,450/2,650-2,800/3,450-3,600 Lumens and 0-10V dimmable functionality, offering efficient lighting. Choose from three color temperatures (3000K, 4000K, 5000K) and select the desired wattage using the Multi Power Switch that is inside the fixture. The fixture is 120-277V and Includes a 120V Pre-wired Dusk to Dawn Photocell which is Removable. The Photocell Response Time is Maximum 3 seconds.

This wattage selectable LED Non-Cutoff Wall Pack, part number LSWX-5-30W-XXK-PC, features a die cast aluminum back plate that is high conductive, waterproof, aging resistant, and salt mist resistant. Built with polycarbonate lens and housing for superior durability and performance. A Threaded 1/2" knockout is provided on the top section of the back.

These LED fixtures have a IP54 Rating - device is partially protected against dust and splashed water. In essence, an IP54 rating suggests the device is suitable for environments where it might encounter dust and occasional splashing, but not submersion in water or heavy dust exposure.

Ideal for general site lighting, loading docks, doorways, pathways, and parking areas. Westgate wall packs come with a 7 year warranty and are rated for 70,000 hours.

Specifications

Manufacturer	Westgate
Color Temperature (Kelvin)	3000K Warm White	4000K Cool White	5000K Daylight
MPN	LSWX-5-30W-30K-PC	LSWX-5-30W-40K-PC	LSWX-5-30W-50K-PC
SKU	LSWX-5-30W-30K-PC	LSWX-5-30W-40K-PC	LSWX-5-30W-50K-PC
UPC	845060073027	845060074253	845060073010
DLC Product ID	PLHV2RQJE3Y6	PLV0MP2NVPRV	PL5VU58RGQOJ
Lighting Technology	LED
Wattage	5/10/20/30 Watts
Voltage	120-277V
Lumens	600-3,600 Lumens
Dimmable	Yes, 0-10V Dimming
Beam Angle	90° x 110°
Rated Life	70,000 Hours
CRI (Color Rendering Index)	70 CRI
Power Factor	>0.90
Finish Color	Bronze
Housing	Polycarbonate with Die-cast aluminum Back Plate
Lens	Polycarbonate
Operating Temperature	-4ºF to 104ºF
Dimensions	11” L x 6 5/6” W x 5 1/5” H
Environment	Wet Location
Certifications	IP54 Rated, UL Listed, DLC Premium Listed
Warranty	7 Year Standard

Wattage	5 Watts
Color Temperature (Kelvin)	3000K Warm White	4000K Cool White	5000K Daylight
Lumens	600 Lumens	630 Lumens	660 Lumens

Wattage	10 Watts
Color Temperature (Kelvin)	3000K Warm White	4000K Cool White	5000K Daylight
Lumens	1,350 Lumens	1,400 Lumens	1,450 Lumens

Wattage	20 Watts
Color Temperature (Kelvin)	3000K Warm White	4000K Cool White	5000K Daylight
Lumens	2,650 Lumens	2,730 Lumens	2,800 Lumens

Wattage	30 Watts
Color Temperature (Kelvin)	3000K Warm White	4000K Cool White	5000K Daylight
Lumens	3,450 Lumens	3,550 Lumens	3,600 Lumens

Documents

Westgate 5/10/20/30 Watt LED Non-Cutoff Bronze Wall Pack Specification Sheet

Westgate 5/10/20/30 Watt LED Non-Cutoff Bronze Wall Pack Installation Instructions

Westgate 5/10/20/30 Watt LED Non-Cutoff Bronze Wall Pack 3000K DLC Product Listing

Westgate 5/10/20/30 Watt LED Non-Cutoff Bronze Wall Pack 4000K DLC Product Listing

Westgate 5/10/20/30 Watt LED Non-Cutoff Bronze Wall Pack 5000K DLC Product Listing
