Name: 5 and 6 Inch Gimbal Recessed LED Downlight
Brand: Nicor
SKU: DLG56-10-120V-2K
Price: 62.62 USD
Availability: InStock

Nicor 5 and 6 Inch Gimbal Recessed LED Downlight

Damp Location Rated, Title 24 Compliant

Price

Color Temp

2700K

3000K

4000K

Quantity

Free Shipping on Orders Over $750 (contiguous US only)

Most in-stock items ship the same day!

Helping you maximize your green® since 2007!

[{"id":48222040228084,"title":"2700K","option1":"2700K","option2":null,"option3":null,"sku":"DLG56-10-120V-2K","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"5 and 6 Inch Gimbal Recessed LED Downlight - 2700K","public_title":"2700K","options":["2700K"],"price":6262,"weight":680,"compare_at_price":null,"inventory_management":"shopify","barcode":"767706088670","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":48222040260852,"title":"3000K","option1":"3000K","option2":null,"option3":null,"sku":"DLG56-10-120V-3K","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"5 and 6 Inch Gimbal Recessed LED Downlight - 3000K","public_title":"3000K","options":["3000K"],"price":6262,"weight":680,"compare_at_price":null,"inventory_management":"shopify","barcode":"767706087413","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":48222040293620,"title":"4000K","option1":"4000K","option2":null,"option3":null,"sku":"DLG56-10-120V-4K","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"5 and 6 Inch Gimbal Recessed LED Downlight - 4000K","public_title":"4000K","options":["4000K"],"price":6262,"weight":680,"compare_at_price":null,"inventory_management":"shopify","barcode":"767706089196","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

Details
Specifications
Documents
Request A Quote

Details

The DLG4 is the perfect LED downlight for directional accent lighting. It’s easy to use twist-and-turn design allows for fine adjustment of the gimbal position. The 360 degrees of rotation and 35 degrees of adjustable tilt in both directions makes the DLG suitable for sloped ceilings and wall wash. The sleek design enhances any interior space with its flush mounting and aesthetic appeal.

Nicor’s DLG56-10-120V 12-Watt 5 Inch and 6 Inch Gimbal Recessed LED Downlight provides between 1008-1064 Lumens of 120V light. Available in three color temperatures, 2700K, 3000K or 4000K and has a standard 98 Degree Optic. Available in white finish and dimmable down to 10% with most standard dimmers. These fixtures are rated for 36,000 hours and have a 5-year warranty.

Specifications

Manufacturer	Nicor
MPN	DLG56-10-120-2K	DLG56-10-120-3K	DLG56-10-120-4K
SKU	DLG56-10-120-2K	DLG56-10-120-3K	DLG56-10-120-4K
UPC	767706088670	767706087413	767706089196
Color Temperature (Kelvin)	2700K	3000K	4000K
Finish Color	White
Trim Style	Gimbal
Shape	Round
Lighting Technology	LED
Wattage	12 Watts
Voltage	120V
Lumens	1008 Lumens	1034 Lumens	1064 Lumens
Efficiency (Lumens Per Watt)	81 LPW	83 LPW	85 LPW
Dimmable	Yes, Dimmable
Beam Angle	98 Degrees
Rated Life	36,000 Hours
CRI (Color Rendering Index)	94 CRI
Housing	Steel
Lens	Plastic
Operating Temperature	-18C (0 F) to +49C (+120F)
Dimensions	7" MOD x 3.3" H
Environment	Damp Location Rated
Certifications	cULus,CEC, Title 24 Compliant
Warranty	5 Year Warranty

Documents

Nicor 5 and 6 Inch Gimbal Recessed LED Downlight Specification Sheet

Nicor 5 and 6 Inch Gimbal Recessed LED Downlight Installation Instructions
